Pin Assignments
Table 6. 15 pin D-sub connector
Pin Separate H/V Composite H/V Sync-on-green
1 Red Red Red
2 Green Green Green + H/V Sync
3 Blue Blue Blue
4 GND GND GND
5 GND (DDC Return) GND (DDC Return) GND (DDC Return)
6 GND-Red GND-Red GND-Red
7 GND-Green GND-Green GND-Green
8 GND-Blue GND-Blue GND-Blue
9 No Connection No Connection Not used
10 GND-Sync/Self Test GND-Sync/Self Test GND-Sync/Self Test
11 GND GND GND
12 DDC _SDA DDC _SDA DDC _SDA
13 H_Sync H/V Sync Not used
14 V_ Sync Not used Not used
15 DDC _SCL DDC _SCL DDC _SCL
