Appendix
Pin Assignments
Table 5. 15-Pin D-SUB connector
Pin No.
15-Pin Side of the
Signal Cable
Pin No.
15-Pin Side of the
Signal Cable
1
2
3
4
5
6
7
8
Red
Green
Blue
GND
GND (DDC Return)
GND-R
GND-G
GND-B
9
10
11
12
13
14
15
NC
GND-Sync/Self test
GND
DDC Data
H-Sync
V-Sync
DDC Clock
Table 6. DVI-D Connector
Pin Signal Assignent Pin Signal Assignen
1 T.M.D.S. Data2- 13 No Connect
2 T.M.D.S. Data2+ 14 +5V Power
3 T.M.D.S. Data2 Shield 15 Ground(for +5V)
4 No Connect 16 Hot Plug Detect
5 No Connect 17 T.M.D.S. Data0-
6 DDC Clock 18 T.M.D.S. Data0+
7 DDC Data 19 T.M.D.S. Data0 Shield
8 No Connect 20 No Connect
9 T.M.D.S. Data1- 21 No Connect
10 T.M.D.S. Data1+ 22 T.M.D.S. Clock Shield
11 T.M.D.S. Data1 Shield 23 T.M.D.S. Clock+
12 No Connect 24 T.M.D.S. Clock-
