Samsung SyncMaster 213T

User’s Manual
Specifications
General (SyncMaster 213T)
General
Model Name SyncMaster 213T
LCD Panel
Size 21.3 inch diagonal
Display area 432(H) x 324(V)
Pixel Pitch 0.27mm(H) x 0.27mm(V)
Type a-si TFT active matrix
Viewing Angle 170 / 170 (H / V)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
16,777,216 Colors
Resolution
Optimum resolution 1600 x 1200@60Hz
Maximum resolution 1600 x 1200@60Hz
Input Signal, Terminated
RGB Analog , DVI Compliant Digital RGB.
Composite Sync,SOG, 0.7Vp-p Positive at 75 ohms
Separate H/V sync,TTL level positive or negative
Maximum Pixel Clock
162 MHz
Power Supply
AC 90 ~ 264 VAC, 60/50 Hz ± 3Hz
Signal Cable
15pin-to-15pin D-sub cable, detachable
DVI-D to DVI-D connector, detachable
Power Consumption
75W (Maximum)
Dimensions (WxDxH)
473.4 x 58.8 x 374.0mm(Without Stand)
473.4 x 220.3 x 458.1 mm
Weight
5.1kg (After installation of Stand)
VESA Mounting Interface
100mm x 100mm (for use with Specialty(Arm) Mounting hardware.)
