General
General
Model Name SyncMaster 540N
LCD Panel
Size 15 " Diagonal (38 cm)
Display area 304.1 mm (H) x 228.1 mm (V)
Pixel Pitch 0.297 mm (H) x 0.297 mm (V)
Synchronization
Horizontal 30 ~ 61 k Hz
Vertical 56 ~ 75 Hz
Display Color
16.2 M Colors
Resolution
Optimum resolution 1024 x 768@60 Hz
Maximum resolution 1024 x 768@75 Hz
Input Signal, Terminated
RGB Analog
0.7Vp-p Positive at 75ȍ ±10%
Separate H/V sync, Composite sync, SOG(Option), TTL level positive or negative.
Maximum Pixel Clock
81 MHz
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Signal Cable
15pin to 15pin D-sub cable, Detachable
Dimensions (WxHxD)/ Weight (Simple Stand)
337.5 x 336.8 x 180.0 mm / 13.3 x 13.3 x 7.1 inch (with Basic Stand) / 2.75 kg
Dimensions (WxHxD)/ Weight (Pivot Stand)
