Specifications
General
General
Model Name SyncMaster 632NW
LCD Panel
Size 15.6 " Wide Diagonal (42 cm)
Display area 377.23 mm (H) x 193.54 mm (V)
Pixel Pitch 0.225 mm (H) x 0.252 mm (V)
Synchronization
Horizontal 31 ~ 50 kHz
Vertical 56 ~ 75 Hz
Display Color
16.7M
Resolution
Optimum resolution 1360 x 768@60 Hz
Maximum resolution 1360 x 768@60 Hz
Input Signal, Terminated
RGB Analog
0.7 Vp-p ± 5 %
Separate H/V sync, Composite, SOG
TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
85 MHz (Analog)
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz
Signal Cable
15pin - to - 15pin D-sub cable, Detachable
Dimensions (W x H x D) / Weight (Simple Stand)
382 x 260 x 64 mm / 15.0 x 10.2 x 2.5 inch (Without Stand)
382 x 308 x 159 mm / 15.0 x 12.1 x 6.3 inch (With Stand), 2.5 kg / 5.5 lbs
Environmental considerations
Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)
Humidity : 10 % ~ 80 %, non-condensing
48
