User’s Guide 23
O n -Screen Display
Follow these instructions to get a close-up or a longshot view of the
monitor's viewing area.
1 Push the Menu( ) button.
2 Push the button or button until the Position/Size screen is dis-
played. Push the button or button to select zoom.
3 Push the Menu( ) button to open the zoom adjustment screen.
4 Use the button to decrease the screen viewing area. Use the but-
ton to enlarge the screen viewing area.
Adjust the parallelogram setting when the display is leaning left or
right; adjust the rotation setting when the entire display is tilted left
or right.
1 Push the Menu( ) button.
2 Push the button or button until the Geometry screen is displayed.
3 Push the Menu( ) button to open the Parallel/Rotation adjustment
screen.
4 Use the button or button to adjust the parallel setting; Use the
button or button to adjust the rotation setting.
Zoom
Parallel/Rotation
Menu How to adjust
