Model
Specifications
General
Model Name SyncMaster 932NW
LCD Panel
Size 19 " Wide Diagonal (48 cm)
Display area 408.24 mm (H) x 255.15 mm (V)
Pixel Pitch 0.2835 mm (H) x 0.2835 mm (V)
Synchronization
Horizontal 30 ~ 81 kHz
Vertical 56 ~ 75 Hz
Display Color
8 bit color (16,7 M)
Resolution
Optimum resolution 1440 x 900@60 Hz
Maximum resolution 1440 x 900@75 Hz
Input Signal, Terminated
RGB Analog,
0.7 Vp-p ± 5 %, TTL level (V high
≥
2.0 V, V low
≤
0.8 V)
Maximum Pixel Clock
137 MHz (Analog)
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Signal Cable
