User’s Manual 13
Introduction
(The configuration at the back of the monitor may vary from product to product.)
1. Power port Connect the power cord for your monitor to the power port on the back of the monitor.
2. Signal Cable Connect the signal cable to the video port on your computer, video board, video card, or
graphics card.
3. BNC Connectors
(Option) Connect the signal cable to the BNC signal port on the back of your monitor.
4. USB Connector Connect the USB cable to the USB port on the back of your monitor.
Note:
See Connecting Your Monitor for further information regarding cable connections.
Rear
