User’s Manual 22
Setup
1 Attaching the Base
Base Installation
Attaching and Removing the Bose
1. Place the monitor upside-down on a flat work
surface.
2. Align the tabs on the base with the corresponding
slots on the bottom of the monitor.
3.Press the base onto the monitor until the tabs
are fully engaged in the slots.
4. Push the base toward the front of the monitor until
the release latch clicks into the locked position.
* Do not bend the snap.
