SERVICE
Manual
CONTENTSAIR CONDITIONER
1. Installation
2. Disassembly and Reassembly
3. Troubleshooting
4. Exploded Views and Parts List
5. Refrigerating Cycle Block Diagrams
6. Wiring Diagrams
7. Schematic Diagrams
ROOM AIR CONDITIONER
INDOOR UNIT
AS24A2QC
AS18A2QC
OUTDOOR UNIT
US24A2QC
US18A2QC
E DB68-00277A(6)
cover 5/14/01 8:39 PM Page 1

Questions and Answers

  • Q
    qvaldezAug 12, 2025
    How to stop the COOL LED from blinking on my Samsung US24A2QC?
    • M
      Mrs. Ruth Guzman MDAug 12, 2025
      When you first plug in your Samsung Air Conditioner, the green COOL operation LED will blink to indicate that power is on. Press the ON/OFF button on the remote to stop the blinking.
  • P
    pgibsonAug 16, 2025
    What does it mean if the TIMER LED is blinking on my Samsung US24A2QC?
    • N
      nicholas55Aug 16, 2025
      If the TIMER LED is blinking (1Hz) on your Samsung Air Conditioner, it indicates an indoor unit room sensor error (open or short).
  • L
    lsmithAug 20, 2025
    What does it mean if the OPERATING and TIMER LEDs are blinking on my Samsung US24A2QC?
    • M
      Michael ClarkAug 20, 2025
      If the OPERATING and TIMER LEDs are blinking (1Hz) on your Samsung Air Conditioner, this indicates an error with the indoor unit heat exchanger temperature sensor (open or short).
  • N
    nelsonpamelaAug 23, 2025
    What does it mean if the FAN LED is blinking on my Samsung US24A2QC Air Conditioner?
    • H
      Hunter LeeAug 23, 2025
      If the FAN LED is blinking (1Hz) on your Samsung Air Conditioner, it means the indoor fan is malfunctioning because its speed is below 380 rpm.
  • K
    Kimberly HoltAug 27, 2025
    Why Samsung US24A2QC Air Conditioner does not operate when the Timer LED is on?
    • H
      Hannah RiosAug 27, 2025
      If your Samsung Air Conditioner doesn't turn on and only the Timer LED is lit, the timer function is likely activated, and the unit is in standby mode. Cancel the timer operation to restore normal operation.
  • T
    Timothy WilsonAug 31, 2025
    Why does the compressor stop and fan speed decrease on my Samsung Air Conditioner?
    • J
      Jessica WilliamsAug 31, 2025
      In COOL or DRY mode, the compressor in your Samsung Air Conditioner may intermittently stop, and the fan speed may decrease to prevent the air from freezing inside or outside, depending on the ambient temperature.
  • A
    Alison ReynoldsSep 3, 2025
    Why can't I set the fan speed on my Samsung US24A2QC Air Conditioner in AUTO or DRY mode?
    • J
      Jamie FranklinSep 3, 2025
      When your Samsung Air Conditioner is in DRY mode, the indoor fan speed is automatically set to LL (Low). In AUTO mode, the fan speed is automatically selected from 5 steps.
  • Y
    ygreenSep 7, 2025
    Why does the compressor stop intermittently in DRY mode on my Samsung US24A2QC Air Conditioner?
    • H
      Hannah AdamsSep 7, 2025
      In DRY mode, the compressor in your Samsung Air Conditioner is automatically controlled based on the room temperature and humidity.

Summary

Installation

Refrigerant Refill Procedure

Step-by-step guide for refilling refrigerant in the air conditioner system.

Pump Down Procedure

Procedure for recovering refrigerant before servicing or relocating the unit.

Disassembly and Reassembly

Indoor Unit Disassembly Guide

Instructions for taking apart the indoor unit for maintenance or repair.

Outdoor Unit Disassembly Guide

Instructions for taking apart the outdoor unit for maintenance or repair.

Troubleshooting

Initial Checks and Problem Identification

Basic checks and explanations of common operating symptoms and error codes.

Symptom-Based Fault Diagnosis

Detailed troubleshooting flowcharts for diagnosing specific operational faults.

Exploded Views and Parts List

Indoor Unit Components

Exploded diagrams and part numbers for the indoor unit assembly.

Outdoor Unit Components

Exploded diagrams and part numbers for the outdoor unit assembly.

PCB Box Components

Exploded diagrams and part numbers for the PCB enclosure components.

Refrigerating Cycle Block Diagram

PCB Diagrams

Main PCB Layout and Component Details

Detailed schematic of the main control board, including component layout and connections.

Wiring Diagrams

Indoor Unit Wiring

Schematic showing internal wiring and external connections for the indoor unit.

Outdoor Unit Wiring

Schematic showing internal wiring and external connections for the outdoor unit.
