- 4 -
DESCRIPTION OF PARTS
The User’s Manual is for common use.
Make use of the User’s Manual depending upon your washing machine model.
FILTER
Lint will be collected in the
filter during washing.
LID
Be sure to keep the lid closed
during washing and spinning.
PULSATOR
FRONT CONTROL PANEL
ADJUSTABLE LEGS
Adjust the length of the legs when
installing the washer.
WATER SUPPLY HOSE (HOT)
WATER SUPPLY HOSE (COLD)
DRAIN-HOSE (PUMP)
DETERGENT BOX
SPIN BASKET
POWER CORD
GROUND WIRE
When the water pipe is metal, make sure to
cover the end of the ground wire.
WATER DRAIN HOSE
SOUND ABSORPTION PANEL
WATERDROP MARK
BLEACH INLET
Silver Nano Health System
To Next Page
