Disassembly and Reassembly_13
3-2.STANDARD DISASSEMBLY DRAWINGS
Thisisastandarddisassemblydiagramandmaydifferfromtheactualproduct.
Usethismaterialasareferencewhendisassemblingandreassemblingtheproduct.
Partname Description Figure
ASSYCOVER
TOP
1.Removethetwoscrews
holdingtheTopCoveratthe
backoftheunit.
2.Removethetop-coverby
pullingitback.
3.Then,theWater(Pressure)
Sensor,NoiseFilterandWater
Valvecanbereplaced.
NOISEFILTER
VALVEWATER
WATER(PRESSURE)SENSOR
