22 _ Disassembly and Reassembly
 Disassembly
Part Figure Description
Frame Front
Beforeyoustart,disassembleAssyCoverTop,Assy
PanelControl.
 Becarefulnottotearupthediaphragm.
1. Usinglongnosepliers,pickuponeofthe
ringsonWire-Diaphragmwhichconnectthe
springandthewireends.Then,separatethe
Wire-DiaphragmfromtheFRAME-FRONTand
DisconnecttheDiaphragm.
2. Remove2screwsholdingtheDOOR-LOCK
switchwith(+)screwdriver.
3. Disassembletheterminal(theblueboxis
terminallocation)bypressingthebluecircle
partandremove2screwsholdingtheFrame
Frontwith(+)screwdriver.
4. Pressthecircledplacetoopenupthecover
lter.
5. Remove3screwsholdingthebottomofthe
FRAME-FRONTwith(+)screwdriver.
