28 _ Disassembly and Reassembly
 Disassembly
Part Figure Description
Diaphragm
Beforeyoustart,removecovertop,AssyDrawer,
AssyPanelControlandFrameFront.
1. Unfastenthescrewwith(+)screwdriveron
JointDiaphragmandwirediaphragm.
2. RemoveJointDiaphragmbyhand.
3. Removehoseandclampwithlongnoseplier.
4. Pulldiaphragmtowardsyou.
 Becarefulnottoripdiaphragm.
