Samsung WW80T304MBS - User Manual

Questions and Answers

O
ocopelandAug 10, 2025
Why is my Samsung Washer not draining?
- A
  Amy RobinsonAug 10, 2025
  If your Samsung Washer isn't draining properly, start by clearing the drain pump filter, as it may be dirty. Also, check the drainage pipe for any blockages and dredge it if necessary. If the issue continues, the drain pump itself may have failed and require replacement. Inspect the drain pump wiring harness plug to ensure it's firmly connected; replace the wiring harness if it's faulty. In some cases, a computer board or water level sensor failure could be the cause, necessitating their replacement.
L
Lisa BanksAug 15, 2025
Why is my Samsung WW80T304MBS not filling with water?
- A
  Ashley RothAug 15, 2025
  If your Samsung Washer is not supplying water, first ensure that the faucet is fully turned on and that the water flow is adequate. Check that the drainage pipe is properly suspended. Air level sensor or air collection tube leaks can also cause water supply issues, so inspect the water level sensor and gas manifold assembly. If these steps don't resolve the problem, the inlet valve may be damaged or the computer board may be faulty, requiring replacement. A faulty water level sensor can also cause continuous water level maintenance, so consider replacing it.
J
Johnny BellAug 21, 2025
How to fix water level problem in Samsung WW80T304MBS Washer?
- L
  Logan VelezAug 21, 2025
  If the water level in your Samsung Washer is incorrect, it could be due to several reasons. A common cause is a failure of the inlet valve, which would require replacement. Another potential issue is a faulty computer board, specifically a short-circuited SCR of the water inlet valve, which would necessitate replacing the computer board. Additionally, a malfunctioning water level sensor, indicated by readings outside the normal range (less than 20KHz or more than 50KHz), should be replaced. Finally, ensure that the terminal of the water level sensor is securely plugged in and that the wiring harness is in good condition; replace the wiring harness if necessary.
M
Mr. George MarksAug 27, 2025
What to do if my Samsung WW80T304MBS Washer motor is not working?
- J
  Jackie ChanAug 27, 2025
  If your Samsung Washer experiences a motor issue, start by checking the wiring harness terminals to ensure they are firmly connected. If they are loose or the wiring harness is faulty, replace the wiring harness. Also, if the clothes are too much or stuck, the motor temperature might rise too high, activating thermal protection. In this case, power off the washer and allow it to cool before turning it on again. If the issue persists, the motor itself or the computer board might be faulty, requiring replacement. For variable frequency variants, a UVW short circuit or disconnected wiring could be the cause; inspect the wiring harness or consider replacing the motor. Poor heat dissipation can also be a factor; allow the unit to cool down.
D
Dr. Carol PerrySep 3, 2025
What to do if Samsung WW80T304MBS Washer shows communication error?
- B
  Brittany HarrisSep 3, 2025
  If your Samsung Washer displays communication errors, check the wiring harness terminals to ensure they are firmly connected; replace the wiring harness if it's faulty. A power computer board or display board failure may also be the cause, requiring replacement. In some cases, the computer board or inverter board could be faulty, necessitating their replacement. If you have a motherboard variant, ensure it matches the inverter model and reset variants if necessary.

Summary

Safety Instructions

Safety Guidelines

Essential safety precautions and warnings for operating and servicing the washing machine.

Features and Specifications

Specifications

Detailed technical specifications, dimensions, power consumption, and spin revolutions for different models.

Comparing Specifications with Existing Models

Comparison of features and specifications between different washing machine models.

Accessories

List of included accessories with their descriptions, units, and quantities.

Disassembly and Reassembly

Tools for Disassembly and Reassembly

List of specialized tools required for disassembling and reassembling washing machine components.

Standard Disassembly Drawings

Illustrated step-by-step procedures for disassembling and reassembling various parts of the washing machine.

Troubleshooting

Information Code

Information codes displayed during abnormal conditions, with causes and corrective actions.

Problem Check Point

Common problems encountered with washing machines and their corresponding solutions.

Wiring Diagram

Circuit Diagrams

Detailed circuit diagrams and reference information for electrical connections.

Reference

WW3000 TM Project Name

Details on project naming conventions and model code breakdowns.

Terminology

Definitions of key terms and components used in the service manual.

Samsung WW80T304MBS Specifications

General

Model	WW80T304MBS
Type	Front Load Washer
Capacity	8 kg
Spin Speed	1400 RPM
Energy Efficiency Class	B
Dimensions (W x H x D)	600 x 850 x 550 mm
Weight	65 kg
Color	White
Energy Consumption per 100 Cycles	49 kWh
Water Consumption per Cycle	48 L
Noise Level (Spinning)	72 dB
Digital Inverter Technology	Yes
Drum Clean	Yes
Hygiene Steam	Yes
Quick Wash	Yes
Delay End	Yes
Child Lock	Yes
Digital Inverter Motor	Yes
Eco Bubble Technology	Yes
