Sana 868 - Parts

76
PARTS
Align the red dots
●
on each part and
assemble in the order shown. Once
assembled, turn the drum lid clockwise
to close.
STEP 1
Top-set Assembly
STEP 2
Top-set and body assembly
Place the drum lid on the juicing bowl.
Align the down arrow
▼
on the drum lid
with the OPEN mark on the body and
turn to the CLOSE position.
12. Cleaning Brush11. Rotating Brush 13. Blank Screen
16. Lid Opener 17. Round Brush15. Smoothie Screen
14. Coarse Strainer
9. Auger8. Wiping Blades7. Juicing Strainer
* The products illustrated in this booklet may vary slightly from the actual product. * The products illustrated in this booklet may vary slightly from the actual product.
10. Pusher
4. Juice Tap
2. Juicing Drum
1. Feeding Tube
3. Pulp Cup
Feeding basket Feeding tube
5. Body
6. Juice Cup
+
+
+
+
+
+
