S&C 6801 User Manual

Switch Control Setup
Retry Count
Enter the number of retries to perform on any timeout event. (Range: 0-255; Step: 1;
Default: 1)
Retry Timer
Enter the amount of time in seconds to wait before a retry is attempted. (Range: 0-255;
Step: 1; Default: 5)
Control Point Number
Enter the DNP control point number that activates the Transfer Trip mode in the remote
device. (Range: 0-255; Step: 1; Default: 0)
Protocol
When the remote device is an S&C product select the Peer-to-Peer (P2P) protocol. The
P2P protocol allows the remote S&C device to report the actual opening of the remote
device to the sending device, to allow the IntelliTeam system to proceed with transfer
events.
DNP Control Type
Enter the appropriate control type for the congured Control PT Number setpoint:
Pulse On, Latch On or Breaker Close. When received, the remote control will issue
an Open command to the distributed generation switch.
Commission Test
Selecting the Execute option from the drop-down menu sends a Transfer Trip
command to the target device(s) in the exact same manner that will occur when the com-
mand is sent during normal operation.
WARNING
Performing a Commission Test will operate the target device by sending it an Open
command. A Close command must be sent to the device and any alarms cleared
to put the device in the Ready state.
Test Result
This indicates “Pass,” “Pending,” “Bad Response,” or “No Result” for the sent Prohibit
Restoration command. “Pass” means that the local device received an acknowledge-
ment from the remote device before the Retry Timer expired. “Pending” means that the
local device sent out the test command but is still awaiting a response. “Bad Response“
means that either the remote device rejected the command or the Retry Timer expired
before the local device received an acknowledgement. “No Result” means that no tests
have been performed yet.
Device
This is the Device ID for the remote device.
RTU Address
Enter the address of the remote device. (Range: 0-65519; Step: 1; Default: Not Congured)
Port Code
Select the port to use for transmitting to the remote device. (Default: UDP)
IP Address
When the Port Code is set to “UDP,” enter the IP address of the remote device here.
S&C Instruction Sheet 1045-530 63
