30 S&C Instruction Sheet 662-510
Appendix C
Table 5. Accessories
Item Catalog Number
Grounding jumpers, set of three, with eye-type clamps for
installation with a standard shotgun clamp stick
3-ft (914-mm) cable length 4210
Shotgun clamp sticks for installation of grounding jumpers
and for use with voltage testers
6-ft-5½-in (1969-mm) length 9933-150
8-ft-5½-in (2578-mm)length 9933-151
Storage bag, heavy canvas
For grounding jumpers 9933-149
For shotgun clamp stick
6-ft-6-in (1981-mm) length 9933-152
8-ft-6-in (2591-mm)length 9933-153
Voltage Tester with audio and visual signals, includes voltage tester, batteries, adapter for shotgun clamp sticks, and
storage case
①
9931-072
Pentahead socket, for /-inch drive 9931-074
① For ultimate users other than electric utilities, also specify a
shotgun clamp stick of the appropriate length.
Table 6. Touch-Up Kit Components—Aerosol Coatings in 12-Ounce Cans
Item Catalog Number
S&C light gray outdoor finish 9999-080
S&C olive green (Munsell 7GY3.29/1.5) Outdoor Finish 9999-058
S&C red-oxide primer 9999-061
Table 4. Optional Features—Continued
Item
Suffix to be Added to
Pad-Mounted Gear
Catalog Number
Applicable to Models
Mounting Provisions for Base-Mounted
Surge Arresters
①, at switch terminals and
bus terminals in Compartments 1 and 2
9 kV, 10 kV, or 9/10 kV
-P1
●
All models
12 kV -P3 All models
15 kV -P4 All models
18 kV
-P5
■
All models except PMH-19
Mounting Provisions for Porcelain Cable
Terminators for single-conductor UD cable,
at all cable-connected switch terminals and
bus terminals
G&W PSC for No. 6 through 2/0
▲, or G&W
PAT for No. 4 through 250 kc mil copper or
aluminum cable
-U2 All models
G&W PAT for 3/0 through 750 kc mil
copper or 500 kc mil aluminum cable
▲
-U3 All models
UL Listing. Includes “UL Listed” symbol on ratings label and nameplate
-X
◆▼
All 14.4 kV models
Canadian Standards Association Listing. Includes viewing window with tamper-resistant
cover in switch compartment door(s), and hazard-alerting labels and nameplate per CSA
specification
-Z
□△◇◆
PMH-3, -5, -7, -12
PMH-6, -9
PMH-11, -13, -19
PMH-10
① These provisions accommodate Ohio Brass Type PDV (metal oxide),
McGraw-Edison Type AZL19C (metal oxide), General Electric Tran-
quell® (metal oxide), or McGraw-Edison Type ES (silicon carbide) dis-
tribution-class surge arresters. Surge arresters must be base-mounted
only (with out isolators).
● Not applicable to 25-kV models.
■ Not applicable to 14.4-kV models.
▲ These devices extend below the base of the unit. Provide a cable pit
or specify a base spacer.
◆ UL Listing (catalog number suffix “-X”) cannot be furnished if
Canadian Standards Association Listing (catalog number suffix “-Z”) is
specified and vice versa.
▼ Not available if hexhead actuator for use in lieu of pentahead actua-
tor on all Penta-Latch Mechanisms (catalog number suffix “-B1,” “-B2,”
“-B11,” or “-B12”) is specified.
□ Key interlocks (catalog number suffix “-C3” or “-C4”) must be speci-
fied on gear with fuse compartment(s).
△ Not available if mounting provisions for fault indicator with viewing
window in switch compartment door(s) (catalog number suffix “-F2” or
“-F12”) is specified.
◇ Not available if inner barrier panels (catalog number suffix “-G7)
is specified.
