22
INSTALLATION
GB
10. Adjust the adjustable feet again to obtain
the optimum levelling of the unit.
11. To secure the dishwasher under the table
top, tighten the screws as shown. Note
their positioning for the different types of
worktops.
Wooden Worktop
Granite / Synthetic / Ceramic Worktop
ST3.5x16
Hole Cover
Installation Hook
ST4x14
12. For Marble / Granite Worktop Only
a. Bend the installation hook into a right-
angle.
b. Slot it into the side plane.
c. Secure with 2x screws (Need type of
screws)
SDW60W15N_IB_5L_Final150521.indb 22 21/5/15 12:27 pm
