24
DAB Display Modes
Every time you press INFO on the unit, the display will cycle through the
following display modes.
The information is displayed on the lower segment of the display.
DLS (Dynamic Label Segment)
Dynamic label segment is a scrolling message that the broadcaster may
include with their transmissions. The message usually includes information,
such as program details etc.
Programme Type
This describes the style of the programme that is being broadcast.
Multiplex Name / Frequency
A multiplex is a collection of radio stations that are bundled and
transmitted on one frequency. There are national and local multiplexes.
Local ones contain stations that are specic to that area.
The frequency of the present station will be displayed.
DAB – unlike normal radio, groups together several radio stations
and transmits them on one frequency.
Signal Error/ Signal Strength
The error is shown as a number. If the number is 0, it means the signal
received is error free and the signal strength is strong. If the error rate is
high, it is recommended to reposition the radio aerial or reposition the unit.
The display will show a slide bar to indicate the signal strength, the
stronger the signal, the longer the bar will be from left to right.
Bit Rate / Codec / Channels
The display will show the digital audio bit rate being received with
additional information about the audio codec and channel conguration.
Todays Date
This displays the current date provided automatically by the broadcaster.
SL-DBTB_C_G18_IB_Final190610V2.indd 24 10/06/2019 11:51
