1. POWER – On/Off switch
2. MODE – Mode selector
3. TIMER – Hourly programming
4. SPEED – Fan speed selector
5. TEMP+ - Temperature selector up
6. TEMP- -Temperature selector down
7. SLEEP – Standby mode
8. SWING – Oscillation
INSTALLATION
It is important that the installation instructions below are carefully followed to successfully install
this portable air conditioner. If you have any difficulties or questions regarding these installation
procedures, please contact customer service.
Before installation:
6. Find an area near an electrical outlet.
7. Install the exhaust pipe as shown in the images below (Fig.5 et Fig. 5a).
8. Insert the cable into an AC220~240V/50Hz grounded outlet.
9. As shown in the picture on the next page(Fig.6), connect the drain hose (only
for the model with heating option).
10. Press the 'On/Off' button to turn on the air conditioner.
Fig.5 Fig.5a
