5
Power the radio
1. Battery operation
Installing the batteries, first turn battery cover fixture anti-clockwise
to loosen and pull down the battery cover. Insert 4 x C size (UM-2)
battery into the compartment. Ensure the battery is inserted in
accordance with the diagram shown.
Close the battery cover and fasten the fixture by turning clockwise.
If the radio is not to be used for any extended period of time, it is
recommended that the battery is removed from the radio.
