38
Power supply: AC 120 V 60 Hz
Power consumption: Operation: 110 W
Stand by: 3 W
Weight: 80.5 lbs (36.5 kg)
Dimensions: Width: 25-9/16 inches (650 mm)
Height: 22-1/2 inches (571.5 mm)
Depth: 19-11/16 inches (500.5 mm)
Inputs: VIDEO: 1 V (p-p)/75 ohms
AUDIO: –8 dBm/50k ohms
S-VIDEO: Y: 1 V (p-p), 75 ohms
C: 0.286 V (p-p), 75 ohms
COMPONENT: Y: 1 V (p-p), 75 ohms
P
R: 0.7 V (p-p), 75 ohms
PB: 0.7 V (p-p), 75 ohms
Output: DIGITAL AUDIO : 0.5 V(p-p), 75 ohms
Antenna input: VHF/UHF In 75 ohm coaxial
Picture tube: 27 inches (676.0 mm diagonal)
Tuner type: Quartz PLL Frequency Synthesized
Receiving channels: VHF 2-13
UHF 14-69
CABLE TV 14-36 (A)-(W)
37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)
95-99 (A-5)-(A-1)
100-125 (100)-(125)
01 (5A)
Speaker: 2 inches (50.8 mm) x 3-1/2 inches (88.9 mm), 8 ohm x 2
Sound output power: 1.0 W + 1.0 W
ACCESSORY: Remote control x 1
Specifications
Design and specifications are subject to change without notice.
