Sansui DTV2798A - Electrical Parts List: Diodes and ICs; Diode and Integrated Circuit Listings

ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
CAPACITORS CAPACITORS
C2449 CS0UB0N15K CC 0.1 UF 10V B C2547 CT7RC0P17M CC 10 UF 6.3V C
C2450 CS0UB0N15K CC 0.1 UF 10V B C2548 E62YM2101D CE 100 UF 16V
C2451 CS0UB0N15K CC 0.1 UF 10V B C2549 CS0UB0N15K CC 0.1 UF 10V B
C2452 CS0UB0N15K CC 0.1 UF 10V B C2550 CS0UB0N15K CC 0.1 UF 10V B
C2453 CS0UB0N15K CC 0.1 UF 10V B C2551 CS0UB04K3K CC 0.0027UF 50V B
C2454 CS0UB0N15K CC 0.1 UF 10V B C2552 CS0UB04K3K CC 0.0027UF 50V B
C2455 CS0UB0N15K CC 0.1 UF 10V B C2553 CT7RC0P17M CC 10 UF 6.3V C
C2456 CS0UB0N15K CC 0.1 UF 10V B
DIODES
C2457 CS0UB0N15K CC 0.1 UF 10V B D001 D2WT011E10 DIODE SILICON 11E1-EIC
C2458 CS0UB0N15K CC 0.1 UF 10V B D003 D2WX21DQN9 DIODE SCHOTTKY 21DQ09
C2459 CS0UB0N15K CC 0.1 UF 10V B D004 D2WT011E10 DIODE SILICON 11E1-EIC
C2460 CS0UB0N15K CC 0.1 UF 10V B D005 D97U03R31B DIODE,ZENER MTZJ3.3B T-77
C2461 CS7RC0N17M CC 10 UF 10V C D104 D1VT001330 DIODE,SILICON 1SS133T-77
C2462 CS7RC0N17M CC 10 UF 10V C D105 D2WXSB1400 DIODE SCHOTTKY SB140-EIC
C2463 CT7RC0P17M CC 10 UF 6.3V C D401 D2WT011E10 DIODE SILICON 11E1-EIC
C2464 CS7RC0N17M CC 10 UF 10V C D402 D2WT011E10 DIODE SILICON 11E1-EIC
C2465 CS0UB0N15K CC 0.1 UF 10V B D403 D97U03301B DIODE,ZENER MTZJ33B T-77
C2466 CS0UB0N15K CC 0.1 UF 10V B D404 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
C2467 CS0UB0214K CC 0.01 UF 16V B ! D405 D2LXN49370 DIODE,FAST RECOVERY 1N4937-F
C2468 CS0UB0214K CC 0.01 UF 16V B ! D406 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
C2469 CS0UB0N15K CC 0.1 UF 10V B ! D407 D2LXN49370 DIODE,FAST RECOVERY 1N4937-F
C2470 CS0UB0N15K CC 0.1 UF 10V B ! D408 D2BFRS4FS0 DIODE,SILICON RS-4FS
C2471 CS7RC0N17M CC 10 UF 10V C ! D409 D28F0PRA60 DIODE RECTIFIER 30PRA60-FC
C2472 CS7RC0N17M CC 10 UF 10V C D410 D97U03301B DIODE,ZENER MTZJ33B T-77
C2473 CS0UB0NL5K CC 0.33 UF 10V B ! D411 D2LXN49370 DIODE,FAST RECOVERY 1N4937-F
C2474 CS0UB0413K CC 0.001 UF 50V B ! D412 D2WXN40050 DIODE SILICON 1N4005-EIC
C2475 CS0UB0N15K CC 0.1 UF 10V B D414 D2WT011E10 DIODE SILICON 11E1-EIC
C2476 CS0UB0N15K CC 0.1 UF 10V B D415 D2WT011E10 DIODE SILICON 11E1-EIC
C2477 CS0UB0N15K CC 0.1 UF 10V B D416 D2WT011E10 DIODE SILICON 11E1-EIC
C2478 CS0UB0N15K CC 0.1 UF 10V B ! D501 D2WTRM11C0 DIODE SILICON RM11C-EIC
C2479 CS0UB0N15K CC 0.1 UF 10V B ! D502 D2WTRM11C0 DIODE SILICON RM11C-EIC
C2480 CS0UB0N15K CC 0.1 UF 10V B ! D503 D2WTRM11C0 DIODE SILICON RM11C-EIC
C2481 CS7RC0N17M CC 10 UF 10V C ! D504 D2WTRM11C0 DIODE SILICON RM11C-EIC
C2488 CS0UCH4Q1J CC 47 PF 50V CH ! D505 D2WXSR2900 DIODE SCHOTTKY SR290
C2489 CS0UCH4Q1J CC 47 PF 50V CH ! D506 D2LXN49370 DIODE,FAST RECOVERY 1N4937-F
C2490 CS0UB0413K CC 0.001 UF 50V B D507 D1VT001330 DIODE,SILICON 1SS133T-77
C2494 CS0UB0413K CC 0.001 UF 50V B D508 D97U03R91B DIODE,ZENER MTZJ3.9B T-77
C2495 CS0UCH4Q1J CC 47 PF 50V CH D509 D97U01501B DIODE,ZENER MTZJ15B T-77
C2496 CS0UCH4Q1J CC 47 PF 50V CH ! D510 D28F0PRA60 DIODE RECTIFIER 30PRA60-FC
C2497 CS0UCH4Q1J CC 47 PF 50V CH ! D511 D2LXN49370 DIODE,FAST RECOVERY 1N4937-F
C2498 CS0UCH4Q1J CC 47 PF 50V CH ! D512 D2WXSR2900 DIODE SCHOTTKY SR290
C2499 CS0UB0N15K CC 0.1 UF 10V B D513 D1VT001330 DIODE,SILICON 1SS133T-77
C2501 CS0UB0413K CC 0.001 UF 50V B D514 D1VT001330 DIODE,SILICON 1SS133T-77
C2502 CS0UB0413K CC 0.001 UF 50V B D515 D1VT001330 DIODE,SILICON 1SS133T-77
C2503 CS0UB0413K CC 0.001 UF 50V B D516 D1VT001330 DIODE,SILICON 1SS133T-77
C2504 CS0UB0413K CC 0.001 UF 50V B D517 D2LXN49370 DIODE,FAST RECOVERY 1N4937-F
C2507 CS7RC0N17M CC 10 UF 10V C ! D523 D97U01801B DIODE,ZENER MTZJ18B T-77
C2508 CS7RC0N17M CC 10 UF 10V C D524 D1VT001330 DIODE,SILICON 1SS133T-77
C2509 CS0UCH4S1J CC 56 PF 50V CH D525 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
C2510 CS0UB0N15K CC 0.1 UF 10V B D528 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
C2511 CS0UB0N15K CC 0.1 UF 10V B ! D529 D2WXSR2900 DIODE SCHOTTKY SR290
C2512 CS7RC0N17M CC 10 UF 10V C D530 D97U01001B DIODE,ZENER MTZJ10B T-77
C2513 CS7RC0N17M CC 10 UF 10V C D531 D97U03301B DIODE,ZENER MTZJ33B T-77
C2518 CS0UB0413K CC 0.001 UF 50V B D532 D97U01101B DIODE,ZENER MTZJ11B T-77
C2519 CS0UB0413K CC 0.001 UF 50V B D533 D1VT001330 DIODE,SILICON 1SS133T-77
C2520 CS0UB0413K CC 0.001 UF 50V B D535 D97U04R71B DIODE,ZENER MTZJ4.7B T-77
C2521 CS0UB0413K CC 0.001 UF 50V B D536 D1VT001330 DIODE,SILICON 1SS133T-77
C2522 E72KM0221D CE 220 UF 6.3V D539 D1VT001330 DIODE,SILICON 1SS133T-77
C2523 E72KM0221D CE 220 UF 6.3V D611 D1VT001330 DIODE,SILICON 1SS133T-77
C2524 E72KM0221D CE 220 UF 6.3V D612 D1VT001330 DIODE,SILICON 1SS133T-77
C2525 E72KM0221D CE 220 UF 6.3V D801 D1VT001330 DIODE,SILICON 1SS133T-77
C2530 CS0UCH421J CC 20 PF 50V CH D802 D1VT001330 DIODE,SILICON 1SS133T-77
C2531 CS0UCH421J CC 20 PF 50V CH D803 D1VT001330 DIODE,SILICON 1SS133T-77
C2533 CS0UCH4L1J CC 33 PF 50V CH D810 D1VT001330 DIODE,SILICON 1SS133T-77
C2534 CS0UCH4L1J CC 33 PF 50V CH D811 D1VT001330 DIODE,SILICON 1SS133T-77
C2535 CS0UCH4L1J CC 33 PF 50V CH D812 D1VT001330 DIODE,SILICON 1SS133T-77
C2536 CS0UCH4L1J CC 33 PF 50V CH D2401 DD7R0S3550 DIODE SILICON 1SS355 TE-17
C2537 CS0UCH412J CC 100 PF 50V CH
ICS
C2538 CS0UCH412J CC 100 PF 50V CH ! IC001 I07F9E00W0 VO1=3.33V VO2=0.8-3.3V IO=0.6 BA33E00WHFP-TR
C2539 CS0PB0NH6K CC 2.2 UF 10V B IC005 I0CJ040530 ANALOG SW 3IN-2OUT SN74LV4053APWR
C2540 CS0PB0NH6K CC 2.2 UF 10V B IC101 I56F07180A 2007 USA 27 SD DTV VA OEC7180A
C2541 CS7RC0N17M CC 10 UF 10V C IC102 I9UF032450 RESET IC 4.5V TYPE PST3245NR
C2542 CS7RC0N17M CC 10 UF 10V C IC199 S33A01SE01
MEMORY DATA EEPROM 8K SOIC AT24C08AN-10SU-2.7
C2543 CS7RC0N17M CC 10 UF 10V C IC201 I03FA56760 VIF/SIF IC LA75676V-S
C2544 CS0UB0N15K CC 0.1 UF 10V B ! IC401 I03SD78470 VERTICAL DRIVE 10PIN LA7847-E
C2545 CS7RC0N17M CC 10 UF 10V C ! IC504 000220002W PHOTO COUPLER PS2561AL1-1-V(W)
C2546 CT7RC0P17M CC
10 UF 6.3V C
IC601 I03FC6327B
TV 1CHIP JUMBO 64PIN LA76327M-B-MPB-E
M2-5
