Sansui DTV2798A - Electrical Parts List: Electromechanical Components; Transistors, Coils, Switches, and Transformers

ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
ICS COILS &TRANSFORMERS
IC602 I0QF022830 A/V SW 2INPUT 1 OUTPUT NJM2283M(TE1) T401 0450190171 TRANS,HORIZONTAL DRIVE ETH19Y206AY
IC701 I0QF027500 4INPUT 1OUTPUT AUDIO SW NJM2750M(TE1) ! T501 0481350994 TRANSFORMER,SWITCHING 81350994
IC901 I03FF27000 US MTS DECODER LA72700V-TLM-E
JACKS
! IC1001 I0FSP7822A SOUND AMP 5W*2CH STEREO AN17822A J701 060J431020 RCA JACK MSP-213V2-432_NI_LF
IC2401 I56F069530 USA DTV CHIPSET R8A66953FP J702 063E700012 JACK S4-25SZ
IC2402 ICLJ022EC5 256MB DDR SDRAM
HY5DU561622ETP-D43-C or J703 060J411045 RCA JACK MSP-382V-12_NI_FE_LF
ICLJ022ET5 256MB DDR SDRAM HY5DU561622ETP-D43 J704 060J411032 RCA JACK MSP-213V1-652_NI_LF
IC2403 S33A01SF01 MEMORY DATA 32M BIT FLASH MEMORY K8D3216UTC-PI07 J705 060K421056 RCA JACK AV-5A-66H
IC2405 I1FF043480 AUDIO DAC 192KHZ 24BIT CS4348-CZZR J706 060K421058 RCA JACK AV-5A-68H
IC2406 I0QF0580V0 AUDIO OPERATION AMP NJM4580V(TE1) J707 060K421057 RCA JACK AV-5A-67H
IC2408 I07F0C5WF0 REGULATOR BA00HC5WF-E2 ! J801 066F130026 SOCKET,CATHODE RAY TUBE ISHD62S
TRANSISTORS SWITCHES
Q001 TAAT01281Y TRANSISTOR SILICON KTA1281_Y SW101 0504101T34 SWITCH,TACT EVQ21505R
Q002 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK SW102 0504101T34 SWITCH,TACT EVQ21505R
Q003 T2AA5132E0 FET KTK5132E-RTK/P SW103 0504101T34 SWITCH,TACT EVQ21505R
Q004 T2AA5132E0 FET KTK5132E-RTK/P SW104 0504101T34 SWITCH,TACT EVQ21505R
Q005 T2AA5132E0 FET KTK5132E-RTK/P SW105 0504101T34 SWITCH,TACT EVQ21505R
Q006 T2AA5132E0 FET KTK5132E-RTK/P
VARIABLE RESISTORS
Q007 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK VR401 V1K63H3BTE VOLUME,SEMI FIXED NVG6TLTAB222
Q008 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK VR502 V1163H4BTC VOLUME,SEMI FIXED EVNCYAA03BE4
Q106 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK
P.C.BOARD ASSEMBLIES
Q107 TPAAC05002 COMPOUND TRANSISTOR KRA103SRTK PCB070 A33A01S070 TV MT PCB ASS'Y CMG117B
Q201 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK PCB110 A33A01S110 CRT PCB ASS'Y CCG080B
! Q402 TCAT03227Y TRANSISTOR SILICON KTC3227_Y-AT PCBDH0 A33A01SDH0 DIGITAL PCB ASS'Y CEF284B
! Q405 TDUU024990 TRANSISTOR SILICON 2SD2499(LB0EC1)
MISCELLANEOUS
! Q501 TC4TC32030 TRANSISTOR SILICON KTC3203-Y-BRK(GP) B002 024HC51023 CORE,BEADS FCM1608KF-102T02
! Q502 TJXG10NK50 FET STF10NK50Z B004 024HC51023 CORE,BEADS FCM1608KF-102T02
! Q503 TL4T1371E0 TRANSISTOR SILICON 2SA1371-E (GP) B401 024HT03564 CORE,BEADS W4BRH3.5X6X1.0
Q504 TC4T031980 TRANSISTOR SILICON
KTC3198-AT-GR-BRK(GP) B402 024HT03564 CORE,BEADS W4BRH3.5X6X1.0
! Q505 TT4T2909R0 TRANSISTOR SILICON 2SC2909-R (GP) B405 024HT03564 CORE,BEADS W4BRH3.5X6X1.0
Q506 TNAAD05001 COMPOUND TRANSISTOR KRC104SRTK ! B501 024HT03563 CORE,BEADS W4BRH3.5X6X1.0X2
! Q507 TC4T031980 TRANSISTOR SILICON
KTC3198-AT-GR-BRK(GP) ! B504 024HT03553 CORE,BEADS W5RH3.5X5X1.0
! Q508 TAAT012714 TRANSISTOR, SILICON KTA1271_Y-AT B601 024HT03564 CORE,BEADS W4BRH3.5X6X1.0
Q509 TC4T031980 TRANSISTOR SILICON
KTC3198-AT-GR-BRK(GP) B2401 024HC51513 CORE,BEADS FCM1608KF-151T06
Q510 TNAAD05001 COMPOUND TRANSISTOR KRC104SRTK B2402 024HC51513 CORE,BEADS FCM1608KF-151T06
! Q514 TC4TC32030 TRANSISTOR SILICON KTC3203-Y-BRK(GP) B2403 024HC51513 CORE,BEADS FCM1608KF-151T06
Q601 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK B2404 024HC51023 CORE,BEADS FCM1608KF-102T02
Q602 TT4T03209Y TRANSISTOR SILICON KTC3209-Y(GP) B2405 024HC51023 CORE,BEADS FCM1608KF-102T02
Q603 TAATA12660 TRANSISTOR,SILICON KTA1266-AT(Y,GR) B2406 024HC51023 CORE,BEADS FCM1608KF-102T02
Q605 TPAAB05001 COMPOUND TRANSISTOR KRA102SRTK B2410 024HC51023 CORE,BEADS FCM1608KF-102T02
Q607 TT4T03209Y TRANSISTOR SILICON KTC3209-Y(GP) B2411 024HC51023 CORE,BEADS FCM1608KF-102T02
Q608 TDA0016910 TRANSISTOR SILICON KTD1691Y B2412 024HC51023 CORE,BEADS FCM1608KF-102T02
Q609 TDA0016910 TRANSISTOR SILICON KTD1691Y B2413 024HC51023 CORE,BEADS FCM1608KF-102T02
Q610 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2414 024HC51023 CORE,BEADS FCM1608KF-102T02
Q611 TT4T03209Y TRANSISTOR SILICON KTC3209-Y(GP) B2417 024HC16014 CORE,BEADS HCB3216KF-601T20
Q612 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2418 024HC16014 CORE,BEADS HCB3216KF-601T20
Q701 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2419 024HC16014 CORE,BEADS HCB3216KF-601T20
Q704 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2420 024HC16014 CORE,BEADS HCB3216KF-601T20
! Q801 TCATC3199Y TRANSISTOR SILICON KTC3199_Y-AT B2423 024HC51513 CORE,BEADS FCM1608KF-151T06
! Q802 TCATC3199Y TRANSISTOR SILICON KTC3199_Y-AT ! CD501 120Q414913 CORD AC BUSH P201-2469-2
! Q803 TCATC3199Y TRANSISTOR SILICON KTC3199_Y-AT CD801 WCL6840038 FLAT CABLE AWM2468
AWG26 5C GRAY 400MM
! Q804 TC4TC42170 TRANSISTOR SILICON KTC4217-Y-BRK(GP) CD802 WDL6058038 FLAT CABLE AWM2468 AWG26 6C BLACK 580MM
! Q805 TC4TC42170 TRANSISTOR SILICON KTC4217-Y-BRK(GP) CD804 06E8013001 CORD CONNECTOR E8013001
! Q806 TC4TC42170 TRANSISTOR SILICON KTC4217-Y-BRK(GP) CF201 1012T4R520 FILTER,CERAMIC SFSRA4M50CF00-A0
Q1001 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK CF203 1012T4R519 FILTER,CERAMIC TRAP TPSRA4M50C00-A0
Q2401 T2AA5132E0 FET KTK5132E-RTK/P CF204 102E045R7J FILTER,SAW M1879M
Q2402 T2AA5132E0 FET KTK5132E-RTK/P CP101 069S280639 CONNECTOR PCB SIDE A2001WR2-8P
COILS &TRANSFORMERS
! CP401 069S460089 CORD UX CONNECTOR A1561WV2-A6P
L001 02167BR22K COIL 0.22 UH ! CP502 069S420110 CONNECTOR PCB SIDE A1561WV2-2P
L004 021LA6R22M COIL 0.22 UH CP804 069D01001A CONNECTOR PCB SIDE 003P-2100
L005 021LA6R22M COIL 0.22 UH CD1001 06E8146001 CORD CONNECTOR E8146001
L101 021LA62R2K COIL 2.2 UH CP1001 069S140419 CONNECTOR PCB SIDE A2502WV2-4P
L204 021LA6120K COIL 12 UH CP2401 069S2S001C CONNECTOR PCB SIDE A2003WR2-1FX28P
L205 033702007N COIL 3702007 CP2402 069S2B0639 CONNECTOR PCB SIDE A2001WR2-11P
L206 021LA6270K COIL 27 UH CP801A 067U005049 WIRE HOLDER B2013H02-5P
L207 021L7L220J COIL 22 UH CP801B 067U005049 WIRE HOLDER B2013H02-5P
L208 021LA6330J COIL 33 UH CP802A 067U006049 WIRE HOLDER B2013H02-6P
! L402 022K00058A COIL,LINEARITY 311015027 CP802B 067U006049 WIRE HOLDER B2013H02-6P
! L403 02DK000058 COIL CHOKE 02DK000058 CUS071 800WFAA006 CUSHION A
! L501 029T000152 COIL,LINE FILTER 2R0A902F28YNP or EL0701 124116281A EYE LET XRY16X28BD
029X000098 COIL,LINE FILTER SS28H-20075 EL0702 124120301A EYE LET XRY20X30BD
! L503 028T270021 COIL,DEGAUSS T028R27021 ! F501 081PC6R305 FUSE 51MS063L
L601 021LA6220J COIL 22 UH ! FB401 043227016F TRANSFORMER,FLYBACK FJN27A003_M
L603 021L7L150J COIL 15 UH FH501 06710T0009 HOLDER,FUSE EYF-52BCY
L801 02167D151K COIL 150 UH FH502 06710T0009 HOLDER,FUSE EYF-52BCY
L901 021L7L101J COIL 100 UH NR2401 110P4470M5 R,NETWORK 4D02WGJ0470TCE
L2401 021AS9224J COIL
0.22 UH
NR2402 110P4470M5
R,NETWORK
4D02WGJ0470TCE
M2-6
