Sansui DTV2798A - Replacement Parts Lists Overview; Mechanical and Electrical Components

PART NO. DESCRIPTION PART NO. DESCRIPTION
101 7A701B180A FRONT CABI ASS'Y 7A701B195A FRONT CABI ASS'Y
101A 701WPJD719 CABINET FRONT 701WPJD738 CABINET FRONT
101C 713WPA0239 GUIDE REMOCON 713WPA0218 GUIDE REMOCON
101D 735WPAA484 BUTTON,ASS'Y 735WPA0692 BUTTON,ASS'Y
101E 800WQ00103 FELT SHEET 9*250*T0.3 DELETE
101F 800WQ0A068 FELT SHEET 800WQ0A041 FELT SHEET
104 800WR0A002 SHEET CRT SUPPORT 800WR0A003 SHEET CRT SUPPORT
106 722465A473 SHEET RATING 722465A497 SHEET RATING
111 769WSAA009 WASHER CRT T=1 DELETE
201 8141H60D5U SCREW,TAP TITE(P) GW20 6*45 CH HEXAGON 8141H60D0U SCREW,TAP TITE(P) GW20 6*40 CH HEXAGON
202 811063080U SCREW TAP TITE(P) BRAZIER 3*8 CH 8110630A2U SCREW TAP TITE(P) BRAZIER 3*12 CH
--- 793WCDD810 GIFT BOX 793WCDD879 GIFT BOX
--- 792WHAA097 PACKAGE,TOP (FRONT) 792WHAA138 PACKAGE TOP (FRONT)
--- 792WHAA098 PACKAGE,TOP (BACK) 792WHA0431 PACKAGE TOP(BACK)
--- 792WHAA099 PACKAGE,BOTTOM 792WHAA137 PACKAGE BOTTOM
PART NO. DESCRIPTION PART NO. DESCRIPTION
IC2403
S33A01SF01
MEMORY DATA K8D3216UTC-PI07
S33A08SF02
MEMORY DATA K8P3215UQB-PI4B
MECHANICAL REPLACEMENT PARTS LIST
REF. NO.
DTV2798 DTV2798A
ELECTRICAL REPLACEMENT PARTS LIST
REF. NO.
DTV2798 DTV2798A
