Sansui SLED3900 - Parts and functions

9 EN
Parts and functions
Right sideFront
To display the menu screen.
Press hold VOL (VOLUME) +/– the same time
about 1 sec the menu will be appear.
CH (CHANNEL)
/ buttons, VOL (VOLUME)
+/– buttons and INPUT/ENTER button can be
used to select the desired setting during the menu
screen operations.
Remote sensor
Power Indicator
Red : Standby
Green : On
POWER button
INPUT/ENTER button
VOL (VOLUME)
+/– buttons, MENU
button
CH (CHANNEL)
/ buttons
Rear
PC/DVI AUDIO IN jack
VIDEO1 IN jacks (VIDEO/AUDIO (L/R))
COMPONENT IN jacks
HDMI2 IN jack
PC MONITOR IN jack
ANT. (RF) IN jack
HDMI1/DVI IN jack
DIGITAL AUDIO COAXIAL OUT jack
VIDEO2 IN jacks
(VIDEO/AUDIO (L/R))
VAR.(VARIABLE) AUDIO (L/R) OUT jacks
USB INPUT
