Santos 28 - Wiring Diagram 220-240 V 50;60 Hz Model 28

SANTOS : Instruction and maintenance manual
98168 US 1.0 - 12 2013 www.santos.fr
Electrical wiring diagram 220-240V 50/60Hz
N°28
4
3
2
Starter relay
Blue / White
M
Black
White
~
Red / White
White
Black
White
0
Capacitor
Brown
Blue
A2
A1
1
3
5
13
2
6
14
4
Overload safety
device
White
White
White
White
White
Yellow / White
White
Blue
Violet
White
Black
Green / Yellow
Off
Bowl
tightening
safety
device
r
On
