Edition du 04-2005 Page 19
Replacing springs
Sheets n°2
2/2
-
- Replace springs 3, 4, 5 and 6 with caution
- Remove the rear protective cover and rear upper panel
- Replace both springs(7 and 8) taking care to well position the hooking loops for new
springs in the grooves of plastic hinge bushes
Complementary operations:
-
