Checking the rubber boot and the main shaft
Sheet n°3 ½
Ingrédients : Matériel :
- Grease STRUCTOVIS POO - Screwdriver
- Water
Replace if required
- Rubber foot (ref 32432)
Preliminary Steps
- Switch off the machine using the pause button,squeezers in upper position
- Unplug the machine
Operating procedures:
- Follow the preliminary steps
- Remove the rear protective cover and rear upper panel.
- Check boot (1). Replace if required (presence of tears)
- Remove lower clamp and lift the boot
- Clean the main shaft with water, and dry it.Grease if necessary.
