Parts and Hardware
WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts
are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service.
Never use damaged parts!
Parts and Hardware for STEP 1
NOTE: Not all hardware included will be used.
M6 x 12mm
M8 x 16mm
M6 x 20mm
M8 x 20mm
M6 x 35mm
M8 x 35mm
03
04 06
05 07
08
09
x4
x4 x4
x4 x4
x4
TV Screws
10
x4
x4
M5 x 12mm
M5 x 35mm
Washers
M5
M6/M8
11 12
x4 x4
Spacers
13
x4
