Please read through these instructions completely to be sure you’re comfortable with this easy install process.
Also check your TV owner’s manual to see if there are any special requirements for mounting your TV.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use
of this product, contact Customer Service at 1-888-333-1376 .
Do you have
all the tools
needed?
3
4
CAUTION: Avoid potential personal injuries and property damage!
● This product includes directions and hardware for use with wood stud, solid concrete and concrete block walls –
DO NOT install into drywall alone. For information on how to use this product with steel stud walls contact Customer
Service and ask about the steel stud mounting kit
● The wall must be capable of supporting fi ve times the weight of the TV and mount combined
● Do not use this product for any purpose not explicitly specifi ed by manufacturer
● Manufacturer is not responsible for damage or injury caused by incorrect assembly or use
Ready to
begin?
Awl
Pencil Level
Stud Finder
ScrewdriverTape Measure
7/32 in.
(5.5 mm)
Wood
Drill Bit
Electric Drill
Hammer
1/2 in.
(13 mm)
Socket Wrench
Drill Bit
3/8 in.
(10 mm)
Concrete
1/2 in.
(13 mm)
Steel Stud
Drill Bit
3
Wood Stud Install
Concrete Install
Steel Stud Install
