Sanus WSEPM21 - Page 2

2
Wood Stud Wall
Drywall Only Installation
Solid Concrete or Concrete Block Installation
STEP 1 Attach Wall Plate to Wall
⅛ in. (3 mm)
1 ¾
in. (4.5 cm)
Bit
1
in. (2.5 cm)
Bit
¼ in. (6.5 mm)
¼ in. (6.5 mm)
2 in. (5 cm)
Bit
03
03
01
01
01
01
01
01
02
02
02
03
03
CAUTION: DO NOT overtighten any connections. Tighten ONLY until snug.
