AIRCONDITIONING PRODUCTS
SUBMITTAL SHEET
SYSTEM
INDOOR/OUTDOOR
18K
18K18K
18K L
LL
LS52
S52S52
KS1852/C L
LL
L 1852
WALL MOUNTED LOW AMBIENT AIR CONDITIONER
GENERAL DATA(AT 230V)
POWER V/PH/HZ 230/208 /1/ 60
Circuit Ampacity, Min. (A) 15
Fuse size, Max. (A) 15
COMPRESSOR Rotary-Hermetic
No. used 1
R.L. Amps - L.R. Amps (A) 7.8/8.4-43
Crankcase Heater 20W
OUTDOOR FAN TYPE Propeller
Dia. (in.) - No. used 16-17/32 - 1
Type Drive - No. speeds Direct - 1
No. Poles - RPM (High) 6 - 830
No. Motors - W 1 - 50
CFM (High) 1,390
F.L. Amps. (A) 0.49/0.46
OUTDOOR COIL - TYPE Aluminum Fin & Copper Pipe
Fin Type - Pipe Type Slit Plate - Inner Riffled
Rows - F.P.I. 2 - 24
Face Area (sq.ft.) 5.2
Tube Size (in.) 3/8
INDOOR FAN - TYPE Cross-flow
Dia. & Length (in.) - No. used 3-15/32 & 29-3/8-1
No. speeds 3 & Auto
No. Poles -RPM (High) 4-1,300
No. Motors - W 1 - 30
CFM (HI/MED/LOW) 390/345/315
F.L. Amps (A) 0.25/0.23
INDOOR COIL - TYPE Alminum Fin & Copper Pipe
Fin Type - Pipe type Slit Plate - Inner Riffled
Rows - F.P.I. 2 - 18
Face Area (sq. ft.) 2.64
Tube Size (mm) 7
Drain Connection Size (in.) 23/32
REFRIGERANT R22
Lbs. - R22 (O.D. Unit) 3.77
Control Capillary Tube
Connection Flare
Line Length, Max (ft.) 65
Lift difference, Max (ft.) 23
Line Size - in. O.D. Discharge 1/4
Line Size - in. O.D. Suction 5/8
DIMENSIONS (in.) H x W x D
Indoor Unit -Uncrated 11-7/32 x 39-3/16
x 7-23/32
-Crated 10-7/8 x 42-1/8 x 14-9/32
Outdoor Unit -Uncrated 24-19/32 x 34-21/32 x 12-19/32
-Crated 27-15/16 x 40-9/16 x 16-3/16
WEIGHT INDOOR OUTDOOR
Net (lbs.) 26.5 104
Shipping (lbs.) 33.0 112
Shipping Volume(cu.ft.) 3.78 10.6
SS-18KLS52-3
PERFORMANCE DATA @ ARI STANDARD CONDITIONS (230/208V)
COOLING
Total Capacity(BTU/H) 17,000 / 16,500
Sensible Capacity (BTU/H) 12,200 / 11,950
Latent Capacity (BTU/H) 4,800 / 4,550
SEER 10.4 / 10.4
Dehumidification (Pints/H) 4.4 / 4.3
Amps (A) 7.8 / 8.4
Power Inputs (W) 1720 / 1670
Outdoor Sound Rating (bels) 7.8
FEATURE
Controls Microprocessor
Remote Controller LCD Wireless type
Temperature Control IC Thermostat
Timer Program Timer / 1 hour OFF
Night Setback Built-In
Air Louver (Horizontal) Manual
(Vertical) Auto
Power Failure Automatic Restart Built-In
OPTION
Refrigerant Line Set AP2507BH (20 ft)
AP2510BH (30 ft)
AP2515BH (50 ft)
Low Ambient Control Built-in
Fresh Air Intake N/A
Central Remote ON-OFF Control Available
Airduct Extension N/A
Condensate Drain Pump Available
Non-Removable Remo-con Bracket Available
Air Clean Filter Available
Outdoor unit Mounting Bracket Available
OPERATING RANGE
Cooling
Indoor Air Outdoor Air
Intake Temp. Intake Temp.
Maximum 95 F DB/71 F WB 115 F DB
Minimum 67 F DB/57 F WB
0 F DB
CERTIFICATION
18KLS52
