-2-
N2WLD/YLD
SAFETY PRECAUTION
PRODUCT SAFETY NOTICE
SPECIFICATIONS
Product safety should be considered when a component replacement is made in any area of a receiver. Components
indicated by mark in the parts list and the schematic diagram designate components in which safety can be of
special significance. It is particularly recommended that only parts designated on the parts list in this manual be used
for component replacement designated by mark . No deviations from resistance wattage or voltage ratings may be
made for replacement items designated by mark .
!
!
!
1: An isolation transformer should be connected in the
power line between the receiver and the AC line when a
service is performed on the primary of the converter
transformer of the set.
2: Comply with all caution and safety-related notes
provided on the cabinet back, inside the cabinet, on
the chassis or the picture tube.
3: When replacing a chassis in the cabinet, always be cer-
tain that all the protective devices are installed properly,
such as, control knobs, adjustment covers or shields,
barriers, isolation resistor-capacitor networks etc. Before
returning any television to the customer, the service tech-
nician must be sure that it is completely safe to operate
without danger of electrical shock.
Power source AC 220~240V, 50Hz
Television system System I, B/G, D/K, L.L’
Colour system PAL/NTSC4.43 (PAL/NTSC4.43/NTSC3.58 IN AV MODE)
Receiving channel UHF: #21~69
VHF: E2-E12, F2-F10, R1-R12
Aerial input impedance 75ohm
Rear AV terminal
AV1: CENELEC standard
INPUT: Composite video, RGB and Audio L/R
OUTPUT: TV-output with composite video and audio L/R
AV2: CENELEC standard
INPUT: Composite video, RGB, S-VHS and Audio L/R
OUTPUT: Monitor output with composite video and Audio L/R
AV3: CENELEC standard
INPUT: Composite video and Audio L/R
Side AV terminal
AV4: RCA Jacks
INPUT: Composite video and Audio L/R
AV terminal
AV5: INPUT: Component (Y,Pb,Pr)
HDMI
INPUT: HDMI GROUP Standard
Headphone Socket Mini Jack
CE27LC6BK-C CE32LC6BK-C
Sound output(Continuous) 10W x 2 10W x 2
Contrast Ratio 900:1 1000:1
Display Resolution 1366 x 768 (WXGA) 1366 x 768 (WXGA)
Viewing Angles H: 176°, V: 176° H: 176°, V: 176°
Dimensions (WxHxD) 800 x 473.5 x 234 922 x 544 x 234mm
Weight 12.3 Kg 15.7 Kg
Important recycling information.
Your SANYO product is designed and
manufactured with high quality materials
and components which can be recycled
and reused.
This symbol means that electrical and
electronic equipment, at their end-of-life,
should be disposed of seprately.
In the European Union there are separate collection systems for
used electrical and electronic products.
Please help us to conserve the environment we live in!
Note: This symbol mark and recycle system are applied only to
EU countries and are not applied to other countries of the
world.
RoHS
.This product does not contain any hazardous substances prohibited by the RoHS Directive.
(You will find “R” or “Z” at the last digit of the serial number or an “RSF” label near the rating plate on
the RoHS compliant product.)
WARNING
.You are requested to use RoHS compliant parts for maintenance or repair.
.You are requested to use lead-free solder.
!
!
