CHASSIS ELECTRICAL PARTS LIST
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by a mark in this parts list and the circuit diagram show components whose value have
special significance to product safety. It is particularly recommended that only parts specified on the following
parts list be used for components replacement pointed out by the mark .
!
!
013C5WYS ELECTRICAL PARTS
COIL
L901 645 060 9855 PRE-FORM,D-COIL,28-TOTOKU
PICTURE TUBE
Q901 414 012 4404 CRT A66QEW13X49 SAM BERL.
MISCELLANEOUS
SP901 652 000 0663 SPEAKER 8 OHM 3 WATT 5*9
SP902 652 000 0663 SPEAKER 8 OHM 3 WATT 5*9
W901 645 012 7632 EURO PLUG +2P HOUSE @ 2.1
W902 665 000 2159 GND CON.EB8A 28" 2P C7WLS
1AA0B10H069EA ASSY,PWB,MAIN C5WYS
CAPACITOR
C-R534 403 067 6274 POLYESTER 0.15U J 50V
C003 403 314 5915 GRM21BR71C474KA01L PT297
C004 403 314 5915 GRM21BR71C474KA01L PT297
C005 403 215 2310 GRM188R71H123KA01D PT115
C006 403 215 2310 GRM188R71H123KA01D PT115
C009 403 199 9718 25 YK 470 M TA K1012
C010 403 199 9718 25 YK 470 M TA K1012
C021 403 218 8101 ELECT 100U M 25V
C022 403 233 1517 50 YK 4R7 M TA 0511
C023 403 218 8151 25 YK 1000 M TA 1020
C030 403 113 3815 GRM188R71H102KA01D PT115
C031 403 086 3802 NP-ELECT 10U M 50V
C032 403 086 3802 NP-ELECT 10U M 50V
C033 403 215 2211 GRM188R71H103KA01D PT115
C034 403 215 2211 GRM188R71H103KA01D PT115
C035 403 215 2211 GRM188R71H103KA01D PT115
C036 403 215 2211 GRM188R71H103KA01D PT115
C040 403 113 4119 GRM188R71H222KA01D PT115
C053 403 157 4212 GRM1885C1H221JZ01D PT115
C055 403 157 4212 GRM1885C1H221JZ01D PT115
C057 403 113 3815 GRM188R71H102KA01D PT115
C1001 403 248 1618 16 YK 47 M TA 0511
C1003 403 157 3611 GRM1885C1H101JZ01D PT115
C1005 403 113 3815 GRM188R71H102KA01D PT115
C1006 403 157 3611 GRM1885C1H101JZ01D PT115
C1007 403 113 3815 GRM188R71H102KA01D PT115
C101 403 233 1111 ELECT 22U M 50V
C1011 403 248 1618 16 YK 47 M TA 0511
C1013 403 157 3611 GRM1885C1H101JZ01D PT115
C1014 403 157 3611 GRM1885C1H101JZ01D PT115
C1016 403 113 3815 GRM188R71H102KA01D PT115
C1017 403 113 3815 GRM188R71H102KA01D PT115
C102 403 039 3527 ELECT 470U M 6.3V
C1038 403 323 8815 GRM21BF51C225ZA01K PT115
C1039 403 323 8815 GRM21BF51C225ZA01K PT115
C104 403 233 0817 ELECT 10U M 50V
C106 403 215 2211 GRM188R71H103KA01D PT115
C107 403 215 2211 GRM188R71H103KA01D PT115
!
!
!
!
!
Ref. No.
Part No.
Description
Chassis construction
CE28CN8F-C-00
013C5WYS ELECTRICAL PARTS (PAGE 19)
1AA0B10H069EA ASSY,PWB,MAIN C5WYS (PAGE 19 - 24)
1AA0B10H069EB ASSY,PWB,SOCKET C5WYS (PAGE 24)
Read description in the Capacitor and Resistor as follows:
CAPACITOR
CERAMIC 100P K 50V
Tolerance Symbols:
Less than 10PF
A: Not specified B: ±0.1PF C: ±0.25PF
D: ±0.5PF F: ±1PF G:±2PF
R: ±0.25-0PF S: ±0-0.25PF E: +0-1PF
More than 10PF
A: Not specified B: ±0.1% C: ±0.25%
D: ±0.5% F: ±1% G:±2%
H: ±3% J: ±5% K: ±10%
L: ±15% M: ±20% N: ±30%
P: +100-0% Q: +30-10% T: +50-10%
U: +75-10% V: +20-10% W:+100-10%
X: +40-20% Y: +150-10% Z: +80-20%
Material:
CERAMIC............Ceramic
MT-PAPER ..........Metallized Paper
POLYESTER ......Polyester
MT-POLYEST ......Metallized Polyester
POLYPRO............Polypropylene
MT-POLYPRO ....Metallized Polypropylene
COMPO FILM......Composite film
MT-COMPO ........Metallized Composite
STYRENE............Styrene
TA-SOLID ............Tantalum Solid
AL-SOLID ............Aluminium Solid
ELECT ................Electrolytic
NP-ELECT ..........Non-polarised Electrolytic
OS-SOLID ..........Aluminium Solid with Organic Semiconductive Electrolytic
DL-ELECT ..........Double Layered Electrolytic
RESISTOR
CARBON 4.7K J A 1/4W
Rated Wattage
Performance Symbols:
A: General B: Non flammable Z: Low noise
Other: Temperature coefficient
Tolerance Symbols:
A: ±0.05% B: ±0.1% C: ±0.25% D: ±0.5%
F: ±1% G: ±2% J: ±5% K: ±10%
M:±20% P: +5-15%
Rated value, ohms:
K: 1,000, M: 1,000,000
Material:
CARBON ............Carbon
MT-FILM ..............Metal Film
OXIDE-MT ..........Oxide Metal Film
SOLID..................Composition
MT-GLAZE ..........Metal Glaze
WIRE WOUND ....Wire Wound
CERAMIC RES....Ceramic
FUSIBLE RES ....Fusible
Rated Voltage
Rated value: P=pico farad, U=Micro farad
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
