-21-
C5WYS
Ref. No.
Part No.
Description
Ref. No.
Part No.
Description
C686 403 199 9718 25 YK 470 M TA K1012
C691 403 233 1111 ELECT 22U M 50V
C801 403 269 5916 GRM219R71C224KC01D PT115
C802 403 269 5916 GRM219R71C224KC01D PT115
C803 403 248 2813 50 YK 2R2 M TA 0511
C804 403 269 5916 GRM219R71C224KC01D PT115
C806 403 164 0214 GRM188F51E104ZA01D PT115
C809 403 269 5916 GRM219R71C224KC01D PT115
C811 403 155 2319 GRM188R71H472KA01D PT115
C812 403 164 0214 GRM188F51E104ZA01D PT115
C841 403 042 2425 ELECT 100U M 16V
DIODE
D021 407 149 0817 DIODE 1SS355-TE-17
D1002 407 206 5618 ZENER D. UDZS-TE-1710B
D1003 407 206 5618 ZENER D. UDZS-TE-1710B
D1004 407 206 5618 ZENER D. UDZS-TE-1710B
D1006 407 206 5618 ZENER D. UDZS-TE-1710B
D1007 407 206 5618 ZENER D. UDZS-TE-1710B
D1008 407 206 5618 ZENER D. UDZS-TE-1710B
D1009 407 206 5618 ZENER D. UDZS-TE-1710B
D101 407 149 0817 DIODE 1SS355-TE-17
D1012 407 206 5618 ZENER D. UDZS-TE-1710B
D1013 407 206 5618 ZENER D. UDZS-TE-1710B
D1014 407 206 5618 ZENER D. UDZS-TE-1710B
D1016 407 206 5618 ZENER D. UDZS-TE-1710B
D1017 407 206 5618 ZENER D. UDZS-TE-1710B
D1018 407 206 5618 ZENER D. UDZS-TE-1710B
D1019 407 206 5618 ZENER D. UDZS-TE-1710B
D102 407 100 0333 Z DIODE MTZJ36B 52MM
D1101 407 149 0817 DIODE 1SS355-TE-17
D1102 407 149 0817 DIODE 1SS355-TE-17
D121 407 166 1118 DIODE 1SS356-TW11
D1901 407 063 8626 ZENER DIODE MTZJ-T72-5.1A
D1911 407 116 6504 LD SLP-181B-51
D1911-1 610 269 4710 HOLDER LED A-G2CA
D231 407 206 5618 ZENER D. UDZS-TE-1710B
D232 407 206 5618 ZENER D. UDZS-TE-1710B
D261 407 099 5422 Z DIODE MTZJ6.2B 52MM
D262 407 099 5422 Z DIODE MTZJ6.2B 52MM
D263 407 099 5422 Z DIODE MTZJ6.2B 52MM
D264 407 149 0817 DIODE 1SS355-TE-17
D265 407 149 0817 DIODE 1SS355-TE-17
D266 407 149 0817 DIODE 1SS355-TE-17
D281 407 012 4426 DIODE 1SS133-T-72
D431 407 099 5224 ZENER DIODE MTZJ-T72-5.1B
D438 407 095 8001 DIODE ERD07-15L
D439 407 007 7613 DIODE EU2
D442 407 149 0817 DIODE 1SS355-TE-17
D445 407 149 0817 DIODE 1SS355-TE-17
D446 407 099 6122 Z.DIODE MTZJ-T72-10B
D463 407 012 4426 DIODE 1SS133-T-72
D464 407 099 6924 ZENER DIODE MTZJ-T72-15A
D465 407 149 0817 DIODE 1SS355-TE-17
D466 407 099 7921 Z DIODE MTZJ20B 52MM
D469 407 007 7415 DIODE EU1 52MM
D481 407 007 7415 DIODE EU1 52MM
D482 407 012 4426 DIODE 1SS133-T-72
D501 407 005 8632 DIODE ERA15-02-V1
D502 407 149 0817 DIODE 1SS355-TE-17
D503 407 063 9128 Z.DI0DE MTZJ-T72-6.8B
D504 407 149 0817 DIODE 1SS355-TE-17
D506 407 005 8632 DIODE ERA15-02-V1
D601 407 149 0817 DIODE 1SS355-TE-17
D603 407 006 6310 DIODE ERC05-10B
D604 407 006 6310 DIODE ERC05-10B
D605 407 006 6310 DIODE ERC05-10B
D606 407 006 6310 DIODE ERC05-10B
D610 407 231 7707 PHOTO COUPLE TLP421F
D611 407 006 0130 DIODE ERA91-02
D612 407 200 7806 DIODE RB441Q-40
D613 407 099 5224 ZENER DIODE MTZJ-T72-5.1B
D614 407 091 6724 DIODE AP01C
D615 407 099 7624 ZENER DIODE MTZJ-T72-18B
D616 407 200 7806 DIODE RB441Q-40
D630 407 007 7613 DIODE EU2
D633 407 166 2303 DIODE ERC-91-02L
D635 407 129 6706 DIODE RU4YX LF-L1
D637 407 149 0817 DIODE 1SS355-TE-17
D639 407 007 7415 DIODE EU1 52MM
D641 407 149 0817 DIODE 1SS355-TE-17
D642 407 009 8816 DIODE RU3AM
D645 407 099 5422 Z DIODE MTZJ6.2B 52MM
D648 407 007 7613 DIODE EU2
D671 407 011 3014 DIODE S5277B
D676 407 099 5224 ZENER DIODE MTZJ-T72-5.1B
D681 407 012 4426 DIODE 1SS133-T-72
D841 407 149 0817 DIODE 1SS355-TE-17
INTEGRATED CIRCUIT
IC001 409 569 1907 IC LA42052
IC001-1 610 298 8475 HEAT SINK
IC201 409 586 2010 IC TDA12020 N1
IC501 409 453 5905 IC LA78041
IC501-1 610 309 3338 HEAT SINK-PCC C6BLL
IC601 409 606 0306 IC TN6Q04-E—-N
IC601-1 610 313 8510 HEAT SINK C7WLV 30*47*15
IC641 409 414 3001 IC PQ05RD11
IC666 409 559 9203 IC BA33BC0T
IC801 409 459 4506 IC 24LC16B/P
COIL
L031 645 007 9566 LAL03TB120K P/COIL 52MM
L032 645 007 9566 LAL03TB120K P/COIL 52MM
L035 645 033 2722 BEAD CORE TAIYO YUDEN 52M
L1001 652 000 1718 PIPE CORE
L1002 652 000 1718 PIPE CORE
L1107 645 002 7420 P COIL LAL02TB100K 52MM
L1108 645 002 7420 P COIL LAL02TB100K 52MM
L201 645 008 2887 P.COIL LALO2TB5R6K 52MM
L202 645 008 2887 P.COIL LALO2TB5R6K 52MM
L203 401 027 2135 CARBON 56 JA 1/6W 52MM
L206 645 008 2887 P.COIL LALO2TB5R6K 52MM
L207 645 008 2887 P.COIL LALO2TB5R6K 52MM
L208 645 008 2887 P.COIL LALO2TB5R6K 52MM
L209 645 008 2887 P.COIL LALO2TB5R6K 52MM
L211 645 008 2887 P.COIL LALO2TB5R6K 52MM
L212 645 008 2887 P.COIL LALO2TB5R6K 52MM
L213 645 008 2887 P.COIL LALO2TB5R6K 52MM
L214 645 008 2887 P.COIL LALO2TB5R6K 52MM
L216 645 008 2887 P.COIL LALO2TB5R6K 52MM
L217 645 008 2887 P.COIL LALO2TB5R6K 52MM
L431 645 052 5940 C9HB-1R0K-R INDUCT 1.0UH
L441 645 036 7380 COIL,LINEARITY
L442 610 219 0342 COIL
L461 645 005 5645 AR635LY-1038K 2200UHK
L462 610 000 0261 COIL 349UH
L601A 645 019 3873 LINE FILTER-SAMWHA TECOM
L606 610 078 5946 PIPE CORE
L607 652 000 1817 PIPE CORE BF2030RTM TAPED
L608 652 000 1817 PIPE CORE BF2030RTM TAPED
L632 401 011 9014 CARBON 1R JB 1/4W FLAMPRO
L635 652 000 1718 PIPE CORE
L639 401 011 9014 CARBON 1R JB 1/4W FLAMPRO
L643 401 011 9014 CARBON 1R JB 1/4W FLAMPRO
L801 645 008 2887 P.COIL LALO2TB5R6K 52MM
L802 645 008 2887 P.COIL LALO2TB5R6K 52MM
L803 645 008 2887 P.COIL LALO2TB5R6K 52MM
L804 645 008 2887 P.COIL LALO2TB5R6K 52MM
TRANSISTOR
Q001 405 014 4519 TR BC847B,235 10000/REEL
Q1001 405 134 5925 TR BC857B,235 10000/REEL
Q1002 405 014 4519 TR BC847B,235 10000/REEL
!
!
!
!
!
!
