-14-
C7ZES
Internal power supply
Input Under voltage protection
Oscillator
Falling edge detection
Burst On
Burst Off
Latch for Burst circuit
Logic
4
1
5
3
2
Block Diagram TN6Q03/04
Driver
Over current/FB comparator
Reference Voltage
Over voltage protection
Over heat protection
Latch
Circuit
VDD pin
EDGE pin
FB pin
SOURCE (GND) pin
DRAIN pin
