Sanyo DP19241 Service Manual

GENERAL SPECIFICATIONS
Analog Audio
Mini Pin Jack(φ3.5), STEREO
Digital Audio Output Coaxial
Sub Woofer Out No
DC Jack (Center +) No
Video Input 3 No
Audio Input 3 No
S - Input 3 No
USB (Software Update) No
USB (Time Shift) No
USB (JPEG/MP3/Software Update) No
G-13 Set Size
Approx. W x D x H (mm) 450 x 143 x 337.5
w/o Handle, Stand Approx. W x D x H (mm)
450 x 48 x 307.5
G-14 Weight
Net (Approx.) 2.6kg (5.7lbs)
Net w/o Handle, Stand (Approx.) 2.4kg (5.3lbs)
Gross (Approx.) 3.6kg (8.0lbs)
Gross w/Master Carton (Approx.) --- kg ( --- lbs)
G-15 Carton
Master Carton No
Content --- Sets
Material --- / ---
Dimensions W x D x H(mm) ---
Description of Origin ---
Gift Box Material Single/White
W/Color Photo Label No
W/Handle No
Dimensions W x D x H(mm) 520 x 403 x 128
Description of Origin No
Drop Test 1 Corner / 3 Edges / 6 Surfaces
Height (cm) 80
Container Stuffing (40' container) 2268 Sets/40' container
w/Pallet No
w/Wrapping No
G-16 Material
Cabinet Cabinet Front ABS 94HB
Rear PS 94V0 NON-DECABROM
Stand PS 94HB
Jack Panel --
PCB Non-Halogen Demand No
Eyelet Demand Yes
G-17 Environment
Environmental standard requirement Green procurement of SANYO
Pb-free Phase3(Phase3A)
Measures for Whisker Yes
A3-5

Sanyo DP19241 Specifications

Power

power supply	AC 120V 60Hz
power consumption (operation)	24W
power consumption (stand by)	0.3W

Operating Environment

operating temperature	5˚C - 40˚C
operating humidity	Less than 80% RH

Display

display type	Transmission TFT color LCD panel
display size	47.01 cm
number of pixels	1366 (H) × 768 (V)

Audio

audio output power	2.0W + 2.0W
speaker size	25.4 mm × 68.6 mm
hdmi audio	2-channel PCM

Weight and Dimensions

weight	2.6 kg
width	450 mm
height	337.5 mm
depth	168 mm
