Sanyo DP19241 Service Manual

GENERAL SPECIFICATIONS
G-1 TV
LCD LCD Size / Visual Size 18.50 inch / 470.1mmV
System
LCD Type Color TFT LCD
Number of Pixels 1366(H) x 768(V)
Double Scan No
View Range Left/Right 85/85 degree
Up/Down 80/80 degree
Bright Dot
n≦3
Zero Bright Dot Ratio 70%
Color System NTSC
Speaker 2 Speaker
Position Bottom
Size 1.0 x 2.7 inch
Impedance 8 ohm
Sound Output Max 2.0W + 2.0W
10%(Typical) ---
G-2 Tuning
Broadcasting System Analog US System M
System
Digital ATSC(8VSB)/QAM
Tuner and System 1Tuner
Receive CH Destination US (W/CABLE)
CH Coverage 2~69, 4A, A-5~A-1, A~I, J~W, W+1~W+94
Intermediat
e
Digital 44.00MHz
Frequency Analog Picture(FP) 45.75MHz
Sound(FS) 41.25MHz
FP-FS 4.50MHz
Preset CH No
Stereo/Dual TV Sound US-Stereo
Tuner Sound Muting Yes
G-3 Signal
Video Signal Input Level 1 V p-p/75 ohm
Output Level --
S/N Ratio (Weighted) --
Horizontal Resolution at DVD Mode --
--
RGB Signal Output Level --
Audio Signal Input Level -8.0dBm/50k ohm
Output Level at DVD --
at TV --
Digital Output Level 0.5 V p-p/75 ohm
S/N Ratio at DVD (Weighted) --
Harmonic Distortion --
Frequency Response : at DVD --
at Video CD --
at SVCD --
at CD --
G-4 Power
Power Source AC 120V, 60Hz
DC --
Power Consumption at AC 24W at 120V 60Hz
at DC --
Stand by (at AC) 0.3W at 120V 60Hz
Energy Star Yes
Per Year -- kWh/Year
Protector Power Fuse Yes
Safety Circuit Yes
IC Protector(Micro Fuse) Yes
G-5 Regulation
Safety UL(UL60065_7th)/cUL(CSA E60065_03)
Radiation FCC/IC
Laser --
G-6 Temperature
Operation
+5
o
C ~ +40
o
C
Storage
-20
o
C ~ +60
o
C
Space Around Unit 10cm (4inch)
G-7 Operating Humidity
Less than 80% RH
G-8 Clock and
Clock No
Timer
Sleep Timer Max Time 120 Min
On Timer Program Yes 1Program
Off Timer Program No
Game Timer No
Timer Back-up (at Power Off Mode) more than -- Min Sec
G-9 Remote
Unit RC-RU
Control
Glow in Dark Remocon No
Remocon Format SANYO
Format NEC
Custom Code 38-C7h
Power Source Voltage(D.C) 3V
UM size x pcs UM-4 x 2 pcs
Total Keys 28 Keys
Keys Power Yes
1 Yes
2 Yes
3 Yes
A3-1

Sanyo DP19241 Specifications

Power

power supply	AC 120V 60Hz
power consumption (operation)	24W
power consumption (stand by)	0.3W

Operating Environment

operating temperature	5˚C - 40˚C
operating humidity	Less than 80% RH

Display

display type	Transmission TFT color LCD panel
display size	47.01 cm
number of pixels	1366 (H) × 768 (V)

Audio

audio output power	2.0W + 2.0W
speaker size	25.4 mm × 68.6 mm
hdmi audio	2-channel PCM

Weight and Dimensions

weight	2.6 kg
width	450 mm
height	337.5 mm
depth	168 mm
