Sanyo DP19241 Service Manual

GENERAL SPECIFICATIONS
4 Yes
5 Yes
6 Yes
7 Yes
8 Yes
9 Yes
0 Yes
- Yes
Recall (Quick View) Yes
Sleep Yes
Mute Yes
CH+ / Up Yes
CH- / Down Yes
VOL+ / Right Yes
VOL- / Left Yes
Menu Yes
Reset Yes
Exit Yes
Enter Yes
Input Select Yes
CCD (Closed Caption) Yes
Display Yes
Zoom (Picture Size) Yes
FAV + No
FAV - No
Audio Yes
G-10 Features
Auto Shut Off Yes
Auto Search No
Power On Memory Yes
Hotel Mode Yes
Comb Filter Yes
3 -D
Game Position No
Auto Setup Yes
Language No
TV Location No
Signal Type Yes
Automatic Search Yes
Picture Setting(TV) Yes
Picture Preference Yes
Brightness , Contrast , Color Yes
Tint Yes
Sharpness Yes
Color Temperature Yes
DNR Yes
Backlight Yes
Picture Setting(PC) Yes
HOR Position , VER Position Yes
Phase, Clock Yes
Red, Green, Blue No
Auto Adjust Yes
Audio MTS Yes
Equalizer Mode Yes
Tone Control (Bass/Treble/Balance) Yes
Equalizer Setting Yes
Stable Sound No
Surround Yes
Auto Volume(Automatic Volume Control) Yes
BBE No
SRS WOW (SRS 3D/Focus/Tru Bass) No
HDMI Audio Yes
Speakers(Variable Audio Out) No
Tuning CH Program Yes
Air/Cable Yes
ADD/DELETE Yes
Label CH Label Yes
Video Label Yes
Favorite CH No
V-Chip Yes
Type USA Type
RRT Setup Yes
Lock Hotel Lock No
Channel Lock No
Video Lock No
Panel Lock No
Menu Language
English
DBC (Dynamic Backlight Control) No
Dynamic Gamma Yes
A3-2

Sanyo DP19241 Specifications

Power

power supply	AC 120V 60Hz
power consumption (operation)	24W
power consumption (stand by)	0.3W

Operating Environment

operating temperature	5˚C - 40˚C
operating humidity	Less than 80% RH

Display

display type	Transmission TFT color LCD panel
display size	47.01 cm
number of pixels	1366 (H) × 768 (V)

Audio

audio output power	2.0W + 2.0W
speaker size	25.4 mm × 68.6 mm
hdmi audio	2-channel PCM

Weight and Dimensions

weight	2.6 kg
width	450 mm
height	337.5 mm
depth	168 mm
