— 7 —
POWER BOARD REMOVAL
Remove 2 screws to take off the power unit.
Power Unit
Main Board
MAIN BOARD REMOVAL
Remove 3 screws to take off the main board.
ELECTROSTATICALLY SENSATIVE DEVICES
Many solid-state devices (especially Integrated
Circuits) are Electrostatically Sensitive, and, therefore,
require special handling techniques as described
under “Servicing Electrostatically Sensitive Devices,”
on page two in this service literature.
