— 8 —
MECHANICAL DISASSEMBLY (CONT.)
LEFT SPEAKER REMOVAL
Remove 2 screws and remove the left speaker.
MOUNTING BRACKET AND SPEAKER REMOVAL
Remove 11 screws to take off the mouniting bracket and the right speaker.
Mounting
Bracket
Speaker
(R)
Speaker
(L)
