Repair Flow Chart:Trouble Condition
Green Power LED does not turn on. The TV is dead.
Green Power LED:
Does not turn ON.
The TV is dead.
On analog signal board:
Is the “5VSTB” voltage supplied?
(see TABLE*1.0)
On digital signal board:
Is the “5V_STBY” voltage on
“K5A Pin 3 or Pin 4”?
Analog board is not working.
Replace “analog board”.
Unplug(CN2) connector on
power board. On Power board:
Is the “5VSTB” voltage supplied?
(see TABLE*2.0)
Power board is not working.
Replace “Power board”.
Unplug(K16A) and(K16B) connector
between digital unit and analog unit
Is the “5V_STBY” voltage supplied?
(see TABLE*3.0)
Analog board is not working.
Replace “analog board”.
Replace “digital board”.
While pushing the “power key sw”
is the 2.9V from “key sw2”
supplied to “K16A Pin17”?
Analog board was broken.
Replace “analog board”.
Digital board is not working.
Replace “digital board”.
No:0v
No:0v
Yes:5v
Yes:5v
No:0v
Yes:5v
Yes:5v
No:0v
Yes
No voltage(0v)at K16A Pin17 or 2.9V always present.
(see TABLE*5.0)
Page 1
(TABLE *1.0)Analog board:5VSTB Test Points
42" /46"Models
5VSTB on
Analog
board
Conrmation Voltage
P46841-03 Z5WP
P42841-05 Z5VT
P42841-06 Z5VV
Analog
K17 Pin3 or Pin4
5V
(TABLE *2.0) Power board:5VSTB Test Points
42" /46"Models 5VSTB on Power board Conrmation Voltage
P46841-03 Z5WP
P42841-05 Z5VT
P42841-06 Z5VV
Power CN2 Pin3 or Pin4 5V
(TABLE *3.0)Digital board:5V_STBY Test Points
42" /46"Models
5V_STBY
on
Analog
board
Conrmation Voltage
P46841-03 Z5WP
P42841-05 Z5VT
P42841-06 Z5VV
Analog
K16A Pin3 or Pin4
5V
