Sanyo DVD-1500A User Manual

- 72 -
IC BLOCK DIAGRAM & DESCRIPTION
FL601 VACUUM FLUORESCENT DISPLAY
DISPLAY PATTERN
COLOR OF ILLUMINATION
Blue-green : Unless specified segment color
Red :
ANODE & GRID ASSIGNMENT
G2 G3
G1
G4 G5 G6 G7 G8 G9 G10 G11 G12
S1
S2
S3
S4
S5
S6
S7
S8
S9
S10
S11
S12
S13
S14
S15
S16
DOLBY DIGITAL
DTS
192kHz
96kHz
CONDITION
L
R
ST
FADER
PROGRAM
RANDOM
ANGLE
CHP/ TRK
TITLE
G1 G2 G3~G12
A-B
1
ALL
REPEAT
PBC
LAST MEMORY
1
(1)
CONTINUE
(3)
3
(2)
2
S1
S2
S3
S4
S5
S6
S7
S8
S9
S10
S11
S12
S13
S14
S15
S16
ANODE & GRID ASSIGNMENT
PIN ASSIGNMENT
G3~G12
S4
S9 S8
S3 S2 S1 S5
S13 S14 S15
S12
S16 S10
S6
S7
S7
S11
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
F1 NL NL G1 G2 G3 G4 G5 G6 G7 G8 G9
G10 G11 G12
NL NL NL NL
Pin No.
Assignment
21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
S16 S15 S14 S13 S12 S11 S10 S9 S8 S7 S6 S5 S4 S3 S2 S1 NL NL F2
Pin No.
Assignment
NL
F2
( )
NL
F1
( )
1 40
