Sanyo DWM-1000 Service Manual

- 50 -
PARTS LIST
DIGITAL OUT P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
72 614 314 5738 ASSY,PWB,SW(Only initial)
(1000,US,CA)
72 614 317 9368 ASSY,PWB,SW(Only initial)(XE,UK)
72 614 318 0241 ASSY,PWB,SW(Only initial)(SS)
72 614 318 5536 ASSY,PWB,SW(Only initial)(KR)
72 614 318 7417 ASSY,PWB,SW(Only initial)(AU)
CN420 407 218 1100 PHOTO COUPLE GP1FA550TZ
or 407 215 1608 PHOTO COUPLE TOTX178A
CN421 614 310 2458 PLUG,4P
or 645 005 8110 PLUG,4P
S4200 645 040 6119 SWITCH,SLIDE 2P-2TX2,
PAL-NTSC(XE,UK,AU)
FRONT P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
73 614 314 5776 ASSY,PWB,FRONT(Only initial)
(1000,US,CA)
73 614 317 9375 ASSY,PWB,FRONT(Only initial)(XE,UK)
73 614 318 0258 ASSY,PWB,FRONT(Only initial)(SS,KR)
73 614 318 5833 ASSY,PWB,FRONT(Only initial)(AU)
BR601 614 315 5843 HOLDER,FL,FL_MOUNT
CN601 645 012 5515 SOCKET,FPC 18P
CN602 614 315 8530 ASSY,WIRE
CN603 614 315 8530 ASSY,WIRE
D6001 407 012 4406 DIODE 1SS133
D6002 407 012 4406 DIODE 1SS133
D6003 407 012 4406 DIODE 1SS133
D6004 407 003 4507 DIODE DAP202K
D6850 408 044 8509 LED SLZ-9G55B-24HAB-T1
D6851 408 044 8509 LED SLZ-9G55B-24HAB-T1
D6852 408 044 8509 LED SLZ-9G55B-24HAB-T1
D6853 408 044 8509 LED SLZ-9G55B-24HAB-T1
D6870 407 115 1302 LED SLP-144B-51-A,STANDBY
DS601 407 217 1101 PHOTO DIODE SPS-442-1G,IR
FL601 645 044 8232 FLUORESCENT TUBE,FL
IC601 410 404 1006 IC LC866540A-5V28,MICON
L6000 645 001 4550 INDUCTOR,10U K
or 645 031 7835 INDUCTOR,10U K
Q6001 405 146 2107 TR KTC3875-Y
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
Q6004 405 146 5306 TR KRA102S(SS)
or 405 000 0409 TR DTA114EK
Q6006 405 146 2107 TR KTC3875-Y(SS)
or 405 146 2206 TR KTC3875-GR
or 405 014 4509 TR 2SC2412K-R
or 405 011 1006 TR 2SC1623-L6
REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION
S6100 645 006 5958 SWITCH,PUSH 1P-1T
S6101 645 006 5958 SWITCH,PUSH 1P-1T
S6102 645 006 5958 SWITCH,PUSH 1P-1T
S6103 645 006 5958 SWITCH,PUSH 1P-1T
S6115 645 006 5958 SWITCH,PUSH 1P-1T
S6116 645 006 5958 SWITCH,PUSH 1P-1T
S6117 645 006 5958 SWITCH,PUSH 1P-1T
S6118 645 006 5958 SWITCH,PUSH 1P-1T
S6119 645 006 5958 SWITCH,PUSH 1P-1T
S6120 645 006 5958 SWITCH,PUSH 1P-1T
X6002 645 018 6103 OSC,CERAMIC 6.000MHZ
POWER AMP P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
74 614 314 5783 ASSY,PWB,POWER(Only initial)
(1000,US,CA)
74 614 317 9382 ASSY,PWB,POWER(Only initial)(XE,UK)
74 614 318 0265 ASSY,PWB,POWER(Only initial)(SS,KR)
74 614 318 5840 ASSY,PWB,POWER(Only initial)(AU)
C4705 403 057 2407 POLYESTER 0.1U J 50V
C4706 403 057 2407 POLYESTER 0.1U J 50V
C4750 403 185 0108 MT-POLYEST 0.47U J 50V
C4751 403 184 9805 MT-POLYEST 0.22U J 50V
C4805 403 057 2407 POLYESTER 0.1U J 50V
C4806 403 057 2407 POLYESTER 0.1U J 50V
C4825 403 057 2407 POLYESTER 0.1U J 50V
C4826 403 057 2407 POLYESTER 0.1U J 50V
C4900 403 329 6201 ELECT 2200U M 35V
(1000,SS,KR,US,CA,AU)
C4900
!
!!
404 085 9505 ELECT 2200U M 35V(XE,UK)
C4901 403 329 6201 ELECT 2200U M 35V
(1000,SS,KR,US,CA,AU)
C4901
!
!!
404 085 9505 ELECT 2200U M 35V(XE,UK)
C4910 403 329 6201 ELECT 2200U M 35V
(1000,SS,KR,US,CA,AU)
C4910
!
!!
404 085 9505 ELECT 2200U M 35V(XE,UK)
C4914 403 326 2503 ELECT 1200U M 10V
C4918 404 079 6305 ELECT 10U M 50V(1000,US,CA)
C4924 403 337 1205 ELECT 1200U M 6.3V
CN470 614 310 2496 PLUG,8P
or 645 005 8134 PLUG,8P
CN471 614 310 2342 PLUG,7P
or 645 004 2737 PLUG,7P
CN472 614 310 2465 PLUG,5P
or 645 005 9292 PLUG,5P
CN473 614 315 8752 ASSY,WIRE,POWER-SOCKET_A
CN474 614 310 2458 PLUG,4P
or 645 005 8110 PLUG,4P
CN475 645 006 0939 PLUG,6P
or 614 310 2625 PLUG,6P
CN476 645 006 0960 PLUG,9P
or 614 310 2656 PLUG,9P
CN477 645 006 1905 PLUG,5P
D4730 407 012 4406 DIODE 1SS133
D4731 407 012 4406 DIODE 1SS133
D4750 407 012 4406 DIODE 1SS133
D4900
!
!!
408 043 8005 DIODE G5SBA60L-BU04
D4904
!
!!
407 196 5800 DIODE 1N5402BD82
D4905
!
!!
407 196 5800 DIODE 1N5402BD82
D4906
!
!!
408 044 6208 DIODE SB240L 19C2-105
D4907
!
!!
408 044 6208 DIODE SB240L 19C2-105
HS490 614 264 0159 HEAT SINK(XE,UK,SS,KR)
IC470
!
!!
409 473 9501 IC STK402-230
IC491
!
!!
409 499 5808 IC PQ1CZ31H2ZP,PQ1CZ31H2ZP
IC492
!
!!
409 463 6701 IC KIA7805API
or
!
!!
409 145 2809 IC NJM7805FA
IC493
!
!!
409 499 5808 IC PQ1CZ31H2ZP,PQ1CZ31H2ZP
L4700 614 202 1712 V.H.F COIL 1AV4L20B0320N
or 614 196 9763 V.H.F COIL
D4304
!
!!
407 097 8009 DIODE MPG06G
D4312 407 099 5402 ZENER DIODE MTZJ6.2B
D4313 407 012 4406 DIODE 1SS133
L4300
!
!!
645 038 7364 INDUCTOR,70U
LUG43 645 023 8987 FIXER
Q4310 405 141 3208 TR KTC3198-Y
or 405 141 3307 TR KTC3198-GR
or 405 019 2708 TR 2SC536-F-NP
or 405 019 3804 TR 2SC536-G-NP
Q4311 405 141 3208 TR KTC3198-Y
or 405 141 3307 TR KTC3198-GR
or 405 019 2708 TR 2SC536-F-NP
or 405 019 3804 TR 2SC536-G-NP
R4371
!
!!
614 241 3449 RESISTOR 0.22 K- 5W
RY430
!
!!
645 030 5597 RELAY,PRIMARY
or
!
!!
645 035 6575 RELAY,PRIMARY
T4300
!
!!
645 041 4954 TRANS,POWER
WR430 614 017 8203 TERMINAL BOARD
WR431 614 017 8203 TERMINAL BOARD
