- 51 -

PARTS LIST

REF.NO. PART NO. DESCRIPTIONREF.NO. PART NO. DESCRIPTION

L4800 614 202 1712 V.H.F COIL 1AV4L20B0320N

or 614 196 9763 V.H.F COIL

L4820 614 202 1712 V.H.F COIL 1AV4L20B0320N

or 614 196 9763 V.H.F COIL

L4900 645 043 3054 INDUCTOR,10U

L4901

645 045 7241 INDUCTOR,65U

L4902 645 043 3054 INDUCTOR,10U

L4904

645 045 7241 INDUCTOR,65U

L4905 645 043 3054 INDUCTOR,10U

PR490

645 042 2720 PROTECTOR,5A 125V

PR491

645 042 2652 PROTECTOR,10A 125V

PR492

645 042 2720 PROTECTOR,5A 125V

PR493

645 042 2652 PROTECTOR,10A 125V

Q4700 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4730 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4731 405 143 6504 TR KTA1267-GR

or 405 004 4601 TR 2SA608-F-SPA

or 405 004 5103 TR 2SA608-G-SPA

or 405 006 1806 TR 2SA933S-R

or 405 006 1905 TR 2SA933S-S

Q4732 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4733 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4734 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4735 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4736 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4737 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4738 405 141 3208 TR KTC3198-Y

or 405 141 3307 TR KTC3198-GR

or 405 019 2708 TR 2SC536-F-NP

or 405 019 3804 TR 2SC536-G-NP

Q4739 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4740 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4741 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4750 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4800 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4820 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

Q4910 405 146 1605 TR KRC102S

or 405 000 2908 TR DTC114EK

Q4911 405 146 1605 TR KRC102S

or 405 000 2908 TR DTC114EK

Q4912 405 146 1605 TR KRC102S

or 405 000 2908 TR DTC114EK

Q4920 405 143 8706 TR KTC3199-GR

or 405 017 9600 TR 2SC3330-T

or 405 017 9709 TR 2SC3330-U

or 405 011 8500 TR 2SC1740S-R

or 405 011 8609 TR 2SC1740S-S

R4706

402 081 0403 RESISTOR 4.7 J- 2W

R4707

402 081 0502 RESISTOR 330 J- 3W

R4708

402 081 0403 RESISTOR 4.7 J- 2W

R4716

402 081 1103 FUSIBLE RES 100 JA 1/4W

R4717

402 081 1103 FUSIBLE RES 100 JA 1/4W

R4730

614 241 3449 RESISTOR 0.22 K- 5W

R4799 408 017 0806 TH PTH9M04BB471TS2F333

R4806

402 081 0403 RESISTOR 4.7 J- 2W

R4807

402 081 0502 RESISTOR 330 J- 3W

R4808

402 081 0403 RESISTOR 4.7 J- 2W

R4826

402 081 0403 RESISTOR 4.7 J- 2W

R4828

402 081 0403 RESISTOR 4.7 J- 2W

RY470 614 224 4531 RELAY,SPEAKER

or 645 035 6582 RELAY,SPEAKER

RY480 645 046 1279 RELAY,SPEAKER

or 645 046 1743 RELAY,SPEAKER

PRE AMPLIFIER P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

75 614 315 8080 ASSY,PWB,PRE(Only initial)

(1000,US,CA)

75 614 317 9399 ASSY,PWB,PRE(Only initial)(XE,UK)

75 614 318 0272 ASSY,PWB,PRE(Only initial)(SS,KR)

75 614 318 5857 ASSY,PWB,PRE(Only initial)(AU)

CN440 614 315 8738 ASSY,WIRE,POWER-PRE

CN441 645 047 2060 JACK,PHONE D3.6

CN442 645 047 2060 JACK,PHONE D3.6

CN443 645 047 2060 JACK,PHONE D3.6 (SS,KR)

CN445 614 035 4942 SOCKET,DIP 5P

CN451 614 310 2472 PLUG,6P

or 645 005 8127 PLUG,6P

CN452 614 310 2441 PLUG,3P

or 645 005 7373 PLUG,3P

CN453 645 012 5515 SOCKET,FPC 18P

CN456 614 310 2496 PLUG,8P

or 645 005 8134 PLUG,8P
