- 55 -

PARTS LIST

REF.NO. PART NO. DESCRIPTION

B8058 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8059 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8060 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8061 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8062 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8063 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8064 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8065 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8066 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8069 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8081 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8351 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8353 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8354 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8355 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8400 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8401 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8402 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8403 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8404 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8405 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8406 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8407 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8408 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8409 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8410 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8411 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8412 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8413 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

B8414 645 034 7887 INDUCTOR,1000 OHM

or 645 020 1813 INDUCTOR,1000 OHM

or 645 045 7869 IMPEDANCE,1000 OHM P

CN801 645 010 0772 PLUG,8P

CN805 645 036 4273 PLUG,14P

CN808 645 012 2248 PLUG,4P

CN809 645 041 3810 SOCKET,FPC 26P

CN810 645 041 3803 SOCKET,FPC 16P

CN818 645 020 7228 PLUG,9P

IC101 409 476 6408 IC KS24L161CS,EEPROM

or 409 339 3605 IC 24LC16BT/SN,EEPROM

or 410 394 0904 IC S524L50X51-SCB0,EEPROM

IC102 409 446 7800 IC ADV7170KSU,VIDEO_ENCODER

IC103

409 482 7505 IC BA25BC0FP

IC104

409 416 6406 IC BA033FP

IC105 409 408 9804 IC 74VHC74MTC,D_FRIP_FROP

or 409 415 7909 IC TC74VHC74FT,D_FRIP_FROP

IC110 409 482 0209 IC K4S161622D-TC80,SDRAM2MB

or 410 349 2502 IC EM636165TS-8,SDRAM2MB

or 410 349 2601 IC KM416S1120DT-G8,SDRAM2MB

or 409 482 0209 IC K4S161622D-TC80,SDRAM2MB

IC111 409 482 0209 IC K4S161622D-TC80,SDRAM2MB

or 410 349 2502 IC EM636165TS-8,SDRAM2MB

or 410 349 2601 IC KM416S1120DT-G8,SDRAM2MB

or 409 482 0209 IC K4S161622D-TC80,SDRAM2MB

IC112 409 431 9000 IC 74VHC244MTC

or 410 372 5709 IC MC74VHC244DT-R2

or 410 316 1804 IC TC74VHC244FT-EL

IC113 410 377 4707 IC 74VHCT244AMTC-X

or 410 372 5808 IC MC74VHCT244ADT-R2

or 410 314 3404 IC TC74VHCT244AFT-EL

IC116 409 482 0100 IC L64030,MICON

IC117 409 482 0209 IC K4S161622D-TC80,SDRAM2MB

or 410 349 2502 IC EM636165TS-8,SDRAM2MB

or 410 349 2601 IC KM416S1120DT-G8,SDRAM2MB

or 409 482 0209 IC K4S161622D-TC80,SDRAM2MB

IC118 410 368 2002 IC LE28DW8102T-90-MPB,FLASH

IC127 409 460 3307 IC L64021D,MPEG

IC130 409 482 0001 IC BMR-0302E,RESET

IC131 409 438 7504 IC PCM1723E,DAC

IC132 409 039 8603 IC NJM4560M

IC133 409 484 7602 IC NC7SZ08P5

or 409 368 5809 IC TC7SH08FU

IC135 409 484 7602 IC NC7SZ08P5

or 409 368 5809 IC TC7SH08FU

REF.NO. PART NO. DESCRIPTION
