Page #24 background image

Loading...

Page #24 background image

- 56 -

REF.NO. PART NO. DESCRIPTION

PARTS LIST

REF.NO. PART NO. DESCRIPTION

LOADER P.W.BOARD ASSY

REF.NO. PART NO. DESCRIPTION

79 614 316 6900 ASSY,PWB LOADER(Only initial)

CN100 645 028 6087 SOCKET,FPC 24P

CN200 645 041 3810 SOCKET,FPC 26P

CN500 645 041 3803 SOCKET,FPC 16P

CN540 645 006 0946 PLUG,7P

or 614 310 2632 PLUG,7P

CN600 645 006 0922 PLUG,5P

or 614 310 2618 PLUG,5P

CN610 645 028 8692 SOCKET,FPC 11P

CN620 645 006 2025 PLUG,2P

CN630 645 006 0908 PLUG,2P

or 614 310 2588 PLUG,2P

CN900 645 006 0939 PLUG,6P

or 614 310 2625 PLUG,6P

D1101 407 221 1807 DIODE KDS120E

or 407 179 1805 DIODE DAP222

D1102 407 221 1906 DIODE KDS121E

or 407 162 8507 DIODE DAN222

IC100 409 482 3903 IC LA9702WL-MPB

IC101 409 333 2505 IC BU4066BCF

IC200 409 500 6404 IC LC78661W-D

IC201 409 447 3702 IC T224162B-35S

or 410 367 3604 IC LC324265AT-25DV-TLM

or 409 447 3702 IC T224162B-35S

or 410 375 9407 IC LC324265AT-25DV-MPB

or 410 388 4505 IC M11B416256A-35T

IC500 409 498 8909 IC M37903S4CHP

IC502 409 183 0102 IC M51953BFP

IC504 409 330 9606 IC TC7SHU04FU

or 409 484 7503 IC NC7SZU04P5

IC550 410 337 5201 IC LE28C1001ATS-90-MPB

or 410 382 8509 IC LE28C1001DTS-90-MPB

IC601 409 484 9101 IC BA5937AFP

IC602 409 405 6301 IC BA6849FP

IC900

!

!!

409 416 6406 IC BA033FP

ICX01 410 399 4303 IC ASSY

L1002 645 019 0988 INDUCTOR,1000 OHM

or 645 020 2001 INDUCTOR,1000 OHM

L1003 645 019 0988 INDUCTOR,1000 OHM

or 645 020 2001 INDUCTOR,1000 OHM

L1004 645 019 0988 INDUCTOR,1000 OHM

or 645 020 2001 INDUCTOR,1000 OHM

L1005 645 019 0988 INDUCTOR,1000 OHM

or 645 020 2001 INDUCTOR,1000 OHM

L1006 645 019 0988 INDUCTOR,1000 OHM

or 645 020 2001 INDUCTOR,1000 OHM

L2002 645 019 0988 INDUCTOR,1000 OHM

or 645 020 2001 INDUCTOR,1000 OHM

L2003 645 019 0988 INDUCTOR,1000 OHM

or 645 020 2001 INDUCTOR,1000 OHM

L9001 645 001 5427 INDUCTOR,2.2U M

Q1002 405 014 4509 TR 2SC2412K-R

or 405 146 2206 TR KTC3875-GR

or 405 146 2107 TR KTC3875-Y

or 405 011 1006 TR 2SC1623-L6

Q1003 405 014 4509 TR 2SC2412K-R

or 405 146 2206 TR KTC3875-GR

or 405 146 2107 TR KTC3875-Y

or 405 011 1006 TR 2SC1623-L6

Q1004 405 035 5509 TR 2SA1036K-R

or 405 158 5905 TR KTA1505-Y

Q1005 405 035 5509 TR 2SA1036K-R

or 405 158 5905 TR KTA1505-Y

Q1006 405 014 4509 TR 2SC2412K-R

or 405 146 2206 TR KTC3875-GR

or 405 146 2107 TR KTC3875-Y

or 405 011 1006 TR 2SC1623-L6

Q1007 405 002 0308 TR 2SA1037K-R

or 405 146 9700 TR KTA1504-GR

or 405 134 5905 TR 2SA1037AK-R

or 405 005 5508 TR 2SA812-M6

Q1008 405 014 4509 TR 2SC2412K-R

or 405 146 2206 TR KTC3875-GR

or 405 146 2107 TR KTC3875-Y

or 405 011 1006 TR 2SC1623-L6

Q1009 405 014 4509 TR 2SC2412K-R

or 405 146 2206 TR KTC3875-GR

or 405 146 2107 TR KTC3875-Y

or 405 011 1006 TR 2SC1623-L6

Q1010 405 002 0308 TR 2SA1037K-R

or 405 146 9700 TR KTA1504-GR

or 405 134 5905 TR 2SA1037AK-R

or 405 005 5508 TR 2SA812-M6

Q1011 405 014 4509 TR 2SC2412K-R

or 405 146 2206 TR KTC3875-GR

or 405 146 2107 TR KTC3875-Y

or 405 011 1006 TR 2SC1623-L6

Q1012 405 153 2008 TR 2SK3018

Q1013 405 029 3504 TR DTC144EK

or 405 146 1407 TR KRC104S

or 405 138 6700 TR DTC144EKA

Q1015 405 014 4509 TR 2SC2412K-R

or 405 146 2206 TR KTC3875-GR

or 405 146 2107 TR KTC3875-Y

or 405 011 1006 TR 2SC1623-L6

Q1016 405 014 4509 TR 2SC2412K-R

or 405 146 2206 TR KTC3875-GR

or 405 146 2107 TR KTC3875-Y

or 405 011 1006 TR 2SC1623-L6

Q1017 405 153 2008 TR 2SK3018

Q1018 405 153 2008 TR 2SK3018

Q5020 405 014 4509 TR 2SC2412K-R

or 405 146 2206 TR KTC3875-GR

or 405 146 2107 TR KTC3875-Y

or 405 011 1006 TR 2SC1623-L6

X2000 645 020 9024 OSC,CRYSTAL 16.9344MHZ

X5000 645 045 6466 OSC,CERAMIC 16.0MHZ

IC136 409 484 7503 IC NC7SZU04P5

or 409 330 9606 IC TC7SHU04FU

IC137 409 484 7602 IC NC7SZ08P5

or 409 368 5809 IC TC7SH08FU

L8031 645 037 1608 INDUCTOR,2.2U J

L8032 645 037 1608 INDUCTOR,2.2U J

L8033 645 037 1608 INDUCTOR,2.2U J

L8034 645 037 1608 INDUCTOR,2.2U J

Q8003 405 146 5306 TR KRA102S

or 405 000 0409 TR DTA114EK

Q8004 405 146 1605 TR KRC102S

or 405 000 2908 TR DTC114EK

X8001 645 042 2157 OSC,CRYSTAL

27.000MHZ,27MHZ_OSC
