Sanyo DWM-1000 Service Manual

- 68 -
IC BLOCK DAIGRAM & DESCRIPTION
- VIDEO section -
IC410 MM1508XNRE
(2-Input 1-Output Switch with 6dB AMP)
1
2
3
SW
OUT
Vcc
4
5
6
IN2
GND
IN1
Clamp
Clamp
Bias
DRV.
6dB
IC495 NJM7805FA, KIA7805API (Regulater)
123
1. INPUT
2. COMMON
3. OUTPUT
- MPEG section -
IC101 24LC16BT, S524L50X51 (16K EEPROM)
Name Function
V
SS
SDA
SCL
WP
V
CC
A0,A1,A2
Ground
Serial Address/Data I/O
Serial Clock
Write Protect Input
+2.5V to 5.5V Power Supply
No Internal Connection
4
3
2
1
5
6
7
8
SDA
SCL
WP
V
CC
V
SS
A2
A1
A0
24LC16B
IC103 BA25BCOFP (Voltage Regulater)
1
2
3
Vcc
GND
OUT
Vref
IC104 BA033FP (Regulater)
1
2
3
Vcc
GND
OUT
REFFERENCE
VOLTAGE
1
3
2
OUT
GND
V CC
IC105 74VHC74MTC, TC74VHC74FT (Flip-Flop)
Truth Table
g
Inputs Output
Function
CLR
L
H
L
H
H
H
PR
H
L
L
H
H
H
D
X
X
X
L
H
X
CK
X
X
X
Q
L
H
H(Note 1)
L
H
Qn
Q
H
L
H(Note 1)
H
L
Qn
2
1
3
4
5
6
7
13
14
12
11
10
9
8
CLR1
CLR1
D1 D1
PR1
PR1
Q1
GND
Vcc
CLR2
CLR2
CK2
PR2
PR2
Q2
CK1
Q1
Q1
Q1
D2
D2
Q2
Q2
Q2
CK1
CK2
Clear
Preset
No Change
